It's compatible withall kinds of 12V /24V battery.
For example: lead-acid battery, water battery, maintenance-free battery, dry battery charging. GEL battery , OPZV ,VRLA battery ,Solar battery,ect. and 12.6 V lithium battery Applied to : scooter, motorcycle, car, SUV, small truck, tractor, Outdoor lighting battery any and vehicle batteries ,etc.
Features: MODEL:MF-3S, The core function
1)Automatic identification 12V24V
2)One-button automatic
3)Both ordinary and lithium batteries are suitable
4)400W high power, maximum current 18A,The current can be adjusted manually
5) Compatible with 12.6V lithium battery charging
6) Digital display power, voltage , current .Show charging status in stages
Detailed parameters
Model
MF-3S
power
600W
Input voltage
110V-250V
Frequency
50-60HZ
Output voltage
12V24V
Protection function
Multiple protection
Working Current
0-18A Adjustable automatically
Voltage Identification
12V Peak (8-14.5V);24V Peak (18-29V)
Work Temperature
-30℃ to +35℃
Product size
210*160*87(mm)
Battery type
1. 12V24V battery: Lead-Acid Battery; Maintenance-free battery; Dry battery, Water battery; Gel battery; Solar battery, ect.
2. 12.6V lithium battery
Net weight
1kg
Gross weight
1.2kg
Packing quantity
15Pcs
Carton siza
60X29X49.5CM
Packing Weight
19.4KG
Plug
Optional
input line
150CM
output line
60CM
Charging time reference(Model:XW-30S)
battery(AH)
Charging time(H)
battery(AH)
charging time(H)
6AH-12AH
0.5-1
12AH-20AH
1-2
32-36AH
2-3
45-55AH
3-4
60AH-80AH
6-8
105AH
8-10
120AH
8-14
150AH
9-13
200AH
10-15
300AH
12-19
400AH
14-22
TIP:The larger the true capacity of the battery, the longer it will take to charge.
Package List: 1 * Charger 1 * User Manual(Chinese and English version)
Four stage charging , protect the battery ,non-overcharging
Adaptive electricity charging
Charging at constant voltage
Full charge soon&conduct floating charge Microcurrent supply/full charge
SIX Protections ,Ensure safe charging
Short Circuit protection
Polarity error protection
Overheating protection
Over current protection
low-voltage protection
Over voltage protection
Note: 1. The charger is suitable only for charging matched battery within the listed voltage range. 2. Please do not block cooling fan or use the charger while cooling fan is stopped. 3. Please prevent the charger from rain or water to avoid damage.
