GT Easy construction sideble botani care grow tables greenhouse grow bench
- Category: >>>
- Supplier: Sichuan Green Triangle Technology Co. Ltd.
Share on (62330986175):
Product Overview
Description
1.The moving bench has a standard height of 0.75m and can be fine-tuned.
2.The standard width is 1.7m. It can also be fixed according to the width of the greenhouse.
3.The length is determined according to user requirements.
4.The moving seeded mesh of the moving seedbed net is 130*30 (length*width), hot-dip galvanized material. It has highanti-corrosion performance, good load-bearing capacity and long service life.
The characteristics of the Ebb And Flow Rolling Bench.
1. Watered simultaneously and evenly providing better plant growth.;
2. The hydroponics trays made from thick, durable, high-impact ABS which prevents the bowing or sagging under the weight of large plants or full capacity water.;
3.the products under the double protection of electro-galvanizing + electrostatic spray It is not only beautiful in appearance, but also has double-layer anti-corrosion and strong anti-corrosion ability. It is one of the recommended products;
4.among the several treatment methods of hot-dip galvanizing and dip-coating, it has the most beautiful appearance, strong corrosion resistance and good wear resistance. Especially suitable for greenhouse hot and humid environment but the price is high.
Tape | Bench/Seedbed | |
Length | according to users' requirements. | |
Width | 4ft/5ft/5.5ft/6ft/Customized | |
Height | 30 inch and can be fine-tuned,can be customized | |
Material | Hot-dip Galvanized Steel | |
cover | The cover is fodd grade ABS, 3mm thickness, good performance, good load-bearing capacity and long service life | |
Save water and fertilizer , save labor cost for irrigation | ||
Hydroponic growing ebb and flood bench on wheel for greenhouse is used especially for sub irrigation. Greenhouse ebb and flood bench is used especially for sub irrigation.
Subirrigation is a method of irrigation where water is delivered to the plant root zone from below the soil surface and absorbed upwards. The excess may be collected for reuse.In this system, Bench-mounted tray enclosures holding pots are filled and then drained.
The system consists of a shallow, molded plastic bench top which is flooded with water and fertilizer to both water and feed the plants.When irrigation is complete, the remaining solution drains from the bench and is pumped back to a storage tank.
Subirrigation is a method of irrigation where water is delivered to the plant root zone from below the soil surface and absorbed upwards. The excess may be collected for reuse.In this system, Bench-mounted tray enclosures holding pots are filled and then drained.
The system consists of a shallow, molded plastic bench top which is flooded with water and fertilizer to both water and feed the plants.When irrigation is complete, the remaining solution drains from the bench and is pumped back to a storage tank.
In this system, Special sloped concrete flooring is flooded and drained.The entire floor of the greenhouse is covered with concrete carefully designed and installed to pitch toward openings in the floor. Through these openings the irrigation solution enters to flood the floor and, following flooding, the excess drains back to the storage tank.
Workbench feet
* Rectangular Pipe hot galvanized 32×32× 1.5,anti-corrosin in the welding part 60cm cat walk be-tween each two work bench .
* Aluminum profile frame, light weight and long life service.
* Balance device is added for the workbench to prevent the flowers from rollover.
* Large working space for flowers, workbench area is more than 80% of the total area of greenhouse Max load for flower 40kg/m2 120kg /m2.
Product technology:
The bench net mesh adopts a new reverse welding process to make the mesh surface welding more firm, and the welding head is welded one by one on the warp, with good quality and long working time;
Product features:
The net surface of the fixed bench is flat, the welding is firm, the bearing capacity is good, the size is
accurate; the fixed bench is fully assembled, the site installation is convenient, and the corrosion resistance is durable.
accurate; the fixed bench is fully assembled, the site installation is convenient, and the corrosion resistance is durable.
Bench System:
1.Rolling bench, fixed bench,rotary bench and ebb&flow bench system.
2.High space effiency,convenient for planting and high productive for crops.
2.High space effiency,convenient for planting and high productive for crops.
Shading System:
1.High pressure sodium lamp,or LED lamp;
2.Semi-auto control or intelligent control;
3.Persistant ligh for pants grows.
2.Semi-auto control or intelligent control;
3.Persistant ligh for pants grows.
Cooling system
Cooling fan and cooling pad
Great performance of ventilation Low operating cost Fast cool-down low noise High efficiency motor
Irrigation System:
1.Drip,impulse sprinkler, micro sprinkler and fog spray irrigation system.
2.Water saving and smart.
2.Water saving and smart.
1.Port:Shanghai port & Qingdao port & according to customer's requirements
2.Lead time: 15 days after payment
3.Packing Details： The normal package is carton(Size：L*W*H).But we also pack it according to customer's special request.
You can choose the best way to transport according to your actual situation.
3.Packing Details： The normal package is carton(Size：L*W*H).But we also pack it according to customer's special request.
You can choose the best way to transport according to your actual situation.
Why use Hydroponic growing ebb and flood bench on wheel for greenhouse?
* This system is easy to learn and can be fine tuned to suit a variety of crops.
* This system is easy to learn and can be fine tuned to suit a variety of crops.
* Increase Greenhouse efficiency: improves production capacity by having 70%-80% space in greenhouse.
* Grow plants uniformly and reduce foliar disease.
* Increase in plant uniformity may be the result of more even and complete moistening of the growth medium and better distribution of nutrients absorbed by capillary flow.
* Save labour
* A single person can water thousands of plants by operating the flooding system manually or with the help of a computer.
* Amount of time needed to water the crop drops dramatically.
* Decrease in labor need will help free up workers to do other tasks.
* Save water and fertilizer
* According to research, water and fertilizer usage was cut over 50% by using a close system since water and fertilizer(nutrient solution) are recirculated and not lost by leaching or runoff.
* Less fertilizer is needed, resulting a in lower cost to produce the same quality product.
* Increase safety (Long term benefit)
* It is safer for the environment as water containing fertilizers and chemicals will not leach into our valuable drinking water supplies, helping our children and future generations.
* Less chemicals were needed, cutting down on workers exposure to pesticides and fungicides.
* Reduce risks of getting injuries among workers when doing repetitious manual handling tasks
* Cost effective
* Existing bench frames can be retrofitted.
* The productivity of system is maintained at a high level due to 70%-80% space saving in greenhouse and the reduction of labor, water, fertilizers and chemicals etc.
