ZX 70 High Quality Eco Friendly Paper Straw Making Machine , Paper Straw Manufacturing Equipment Factory
- Category: Straw Making Machines >>>
- Supplier: Wenzhou Zhixin Machinery Co. Ltd.
Share on (62332929619):
Product Overview
Description
Product Description
ZX-70 High Quality Eco Friendly Paper Straw Making Machine , Paper Straw Manufacturing Equipment Factory
The paper pipette machine is a new type of machine specially developed by our company in line with the trend of environmental protection. Suitable for the production and processing of paper straws, the diameter can be 5mm, 6mm, 8mm, 10mm and so on.
The secondary machine is equipped with upper limbs, glued, wound, and cut into one. It is equipped with a CNC multi-tool cutting system. The servo control system controls the stroke and the finished paper straw can be cut online. Compared with other similar devices, the structure is more reasonable, faster and more stable.
SPECIFICATIONS FOR PAPER STRAW MACHINE | ||||||
Model | ZX-70 | |||||
Paper layer | 3layer | |||||
Paper speed | 70m/min | |||||
Straw outer speed | 60m/min | |||||
Inner diameter | 4.5-12mm | |||||
Straw thickness | 0.3-2mm | |||||
Cutting knife | seven | |||||
Cutting system | Servo motor | |||||
Gummy way | Single/double side | |||||
Dimension(mm) | 3500*1500*1200 | |||||
Paper material | Inner two layer paper 168gsm, outside paper 68gsm. | |||||
Power | 6.8kw | |||||
Machine weight | 1500kg | |||||
Voltage | 380V 50Hz / 220V 50Hz | |||||
Dimension(mm) | 3600*1500*1200 | |||||
Working space (mm) | About 7000*5000mm | |||||
Motor | Schneider(1.5kw) |
Bearing | HRB |
Frequency converter | Schneider(3.7kw) |
PLC | TRIO(United Kingdom) |
Screen | Schneider |
Servo motor | Taiwan TBI |
Electric components | Schneider |
Remarks:
1) Price Term: Ningbo Port, China.
2)Payment term: TT (30% deposit, the balance70% before delivery).
3) Delivery time: 30 working days after receiving the deposit
4) After sale service:
1. Spare parts guarantee for one year from the date of installation.
2. Send the technician for installation & training. Buyer bears the cost (round tickets ,accommodation, and allowance of 80USD per day).
1) Price Term: Ningbo Port, China.
2)Payment term: TT (30% deposit, the balance70% before delivery).
3) Delivery time: 30 working days after receiving the deposit
4) After sale service:
1. Spare parts guarantee for one year from the date of installation.
2. Send the technician for installation & training. Buyer bears the cost (round tickets ,accommodation, and allowance of 80USD per day).
Colorful Paper Straw
Detailed Images
Machine Parts
Name: Incr. Encoder
Brand: SICK
Original: Malaysia
Function: counting paper feed length
Different from others, better for paper feeding and forming
Main Features
Name: Linear guideway
Brand: HIWIN
Original:TAIWAN
Material high-strength steel from Germany, high precision, low noise and high wear resistance, mature heat treatment technology.
Main Features
Name: Bearings
Brand: NACHI
Original:JAPAN
High quality bearings, high machine quality!
Our Service
Provide related supplies
we can provide oll paper and glue which used in paper straw machine.
After-Sales Service
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
Packing & Delivery
Paper Straw Machine Packaging | ||
Size | 3600 (L) * 1600 (W) * 1300 (D) | |
Weight | 1.4 T | |
Packaging Details | The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request. | |
Paper Straw Machine Sea Packaging | ||
Size | 123 (L) * 456 (W) * 789 (D) | |
Weight | 1.2 T | |
Packaging Details | 20GP L × W × H(m) Weight CBM Iinner: 5.898×2.352×2.385 17.5t 28m³ Outer :6.058×2.438×2.591 17.5t 28m³ 40GP L × W × H(m) Weight CBM Iinner: 12.032×2.352×2.385 26t 58m³ Outer:12.192×2.438×2.591 26t 58m³ | |
