plywood making line tree debarking machine

Product Overview

Description

4ft veneer peeling machine		8ft veneer peeling machine		10ft veneer peeling machine
Type	JLXQ130-40A	Type	JLXQ260-50A	Type	JLXQ320-50A
Cutting Size (DxL)	Φ400×1400mm	Cutting Size (DxL)	Φ500×2700mm	Cutting Size (DxL)	Φ500×3300mm
left log Dia.	Φ24mm	left log Dia.	Φ30mm	left log Dia.	Φ35mm
Cutting Thickness	1.0~3.5mm	Cutting Thickness	1.0~3.5mm	Cutting Thickness	1.0~3.5mm
Speed	30~80m/min	Speed	30~80m/min	Speed	30~80m/min
Power	40.5KW	Power	54KW	Power	74KW
Single Roller Dia	101mm	Single Roller Dia	101mm	Single Roller Dia	125mm
Doubel roller Dia.	110mm	Doubel roller Dia.	125mm	Doubel roller Dia.	200mm
Weight	6000kgs	Weight	11000kgs	Weight	13000kgs
Overall size	4100x2150x1600mm	Overall size	6100x2150x1600mm	Overall size	6800x2250x1600mm





Welcome contact us any time  freely !
