Hot Item Din rail type MDR 60 24 60W 24V 2.5A Switch Mode Power Supply SMPS for LED Indicator
Hot Item Din rail type MDR-60-24 60W 24V 2.5A Switch Mode Power Supply SMPS for LED Indicator
Hot Item Din rail type MDR-60-24 60W 24V 2.5A Switch Mode Power Supply SMPS for LED Indicator
Hot Item Din rail type MDR-60-24 60W 24V 2.5A Switch Mode Power Supply SMPS for LED Indicator
Hot Item Din rail type MDR-60-24 60W 24V 2.5A Switch Mode Power Supply SMPS for LED Indicator
Hot Item Din rail type MDR-60-24 60W 24V 2.5A Switch Mode Power Supply SMPS for LED Indicator
Hot Item Din rail type MDR-60-24 60W 24V 2.5A Switch Mode Power Supply SMPS for LED Indicator

Hot Item Din rail type MDR 60 24 60W 24V 2.5A Switch Mode Power Supply SMPS for LED Indicator

Share on (62336781754):


Price:$9.40 - $9.70

Quantity:


Product Overview

Description



Product Description




Specification


SPECIFICATIONS
Model
MDR-60-5
MDR-60-12
MDR-60-24
MDR-60-48
DC Voltage
5V
12V
24V
48V
Rated Current
10A
5A
2.5A
1.25A
Current Range
0-10A
0-5A
0-2.5A
0-1.25A
Rated Power
50W
60W
60W
60W
Ripple & Noise
80mVp-p
120mVp-p
150mVp-p
200mVp-p
Voltage Tolerance
±2%
±1%
±1%
±1%
Line regulation
±1.0%
±1.0%
±1.0%
±1.0%
Load regulation
±1.0%
±1.0%
±1.0%
±1.0%
Setup, Rise Time
500ms,30ms/230VAC 200ms,30ms/115VAC at full load
Hold Up Time
50ms/230VAC 20ms/115VAC at full load
Voltage Range
85~264VAC 47~63Hz; 120~370VDC
AC Current
1.8A/115VAC 1A/ 230VAC
Efficiency
78%
86%
88%
87%
Inrush Current
Cold start 30A/115VAC 60A/230VAC
Leakage Current
<1mA/240VAC
Over Load
105%~150% rated output power
Protection type: Constant current limiting, recovers automatically after fault condition is removed
Over Voltage
6.25-7.25V
15.6-18V
31.2-36V
57.6-64.8V
Protection type: Shut down o/p voltage, re-power on to recover
Working Temp., Humidity
-20℃~+70℃; 20%~90% RH non-condensing
Storage Temp., Humidity
-40℃~+85℃; 10%~95%RH
Temp. Coefficient
±0.03%/℃(0~50℃)
Vibration
10~500Hz, 2G 10min./1cycle, period for 60min, each along X, Y, Z axes
Safety Standard
Design refer to UL508, UL60950-1,TUV EN60950-1,EN50178
EMC Standard
Design refer to EN55011,EN55022,EN61000-3-2,-3,EN61000-4-2,3,4,5,6,8,11,EN55024,EN61000-6-2，EN61204-3, heavy industry level, criteria A
Dimension
40*90*100mm(W*H*D)
Weight
0.33Kg
Packing
42pcs/carton/14.8kg/0.82CUFT
Warranty
2 years


CE din rail power supply 60W 5V ac dc converter
1. Standard carton: 60pcs/carton (49/44*24*32cm strong cardboard carton)
2. Sample carton: 31*25*20cm thickened cardboard carton
3. According to your requirements, the size can be customized
