PROCESS TYPE: 1. Two sheets of steel are overlapped and welded by laser. Laser ring welding is used in the middle of the sheet and two laser welding seals are used around the edge.
2. Injecting high-pressure liquid between plates makes the plates expand and deform under pressure, forming a hollow plate heat exchanger with uneven surface.
Application
WIDE-CHANNEL PLATE-SHELL HEAT EXCHANGER
Combining the advantages of shell-and-tube heat exchanger and plate heat exchanger, it is easy for scaling materials to move between boards and clean materials to move inside boards.
Usually floating head structure design is adopted. When cleaning, the whole group of plate bundles can be pulled out.
WIDE-CHANNEL PLATE-SHELL HEAT EXCHANGER
Specially designed for working conditions with larger particles or higher viscosity, the medium can fully flow in the runner without blockage under the above working conditions. Generally, the solid medium goes between the plates without contacts, and the clean medium goes through the plate cavity with contacts: Flow resistance is small and scaling is not easy. High heat transfer coefficient. Easy to clean.
SURFACE CONDENSER
Condensation of steam Condenser of evaporation station Condenser/Air Cooling Island of Power Station Condensation of Organic Steam Condenser for Distillation/Distillation System Condenser/Evaporative Condenser for Refrigeration System
PLATE HEAT RECOVERY UNIT
It is a special case of plate and shell heat exchanger, which is used to recover various waste steam and waste heat.
DIMPLE JACKET
It has high bearing capacity and can reach up to 5 MPa by special design. Fermentation tank Jacket Reactor Other Heat Exchange Jacket Tanks
CHILL SYSTEM
Used as evaporator in refrigeration system Falling film ice water machine Large Slip Ice Maker
Dehumidifier
The dehumidifier is mainly composed of cooler, separator, etc.
CUSTOMIZED We can design and fabricate heat transfer elements of various materials and arbitrary shapes to meet your special requirements.
Advantage: 1.Unique three-dimensional surface runner: 2.High heat transfer coefficient 3.It is not easy to scale. 4.Not easily blocked 5.Compact structure 6.High temperature and high pressure resistance 7.Fully welded structure 8.Floating Head Design 9.Easy to clean 10.Lower flow resistance
Packing&Delivery
Our Company
Nanjing Kingreat Machinery Co., Ltd , covering an area of 650000m2, there are 2300 staff and employee in our company, 281 of them are technicians and engineers. It has obtained the approvals and certifications of both ISO9001:2008 quality control system and the military product quality certificate, BV and CE certificates. Some of our machines gained the new technology invent patent.
We are one of the world's leading manufacturers of disc centrifuges, decanters, separation systems and marine equipment. We focus on food production, environmental protection, energy recycling, chemistry and marine. Now there are over 150 series of decanter centrifuges and disc separators used both home and abroad.
Our Certification
BEST STAINLESS
Best stainless steel wing nut anchor bolt for construction fastener bags+cartons+pallets according to customer ' s requirement,Best stainless steel wing nut anchor bolt for construction fastener bags+cartons+pallets according to customer ' s requirement,
Our Service
1. 12 months guarantee period from machine arriving date. 2. Abundant spare parts in stock are available to provide. 3. Our technicians could be dispatched for overseas service. 4. 7*24 hours technical consultation. 5. Your workers could get trained both in our factory and yours. 6. Routine tracing till the machine work properly will be done timely. 7. We will remind you to do the normal maintenance. 8. Your suggestions or any comments & reflection would be treated in priority. 9. Marketing team will visit you during our visit in your country if you require.
FAQ
1. How can we visit your factory? If you come from abroad, air to Shanghai airport, then take bullet train, about 1 hour from Shanghai to Nanjing South Station; if you come from our domestic city, air or train directly to Nanjing, we will pick you up both in the airport and railway station. 2. Can we visit your end user or contact them? Yes, users are in domestic and abroad, we can provide you the name list, you can go there or contact for more info.
3. How do you protect the quality? Our factory is a state owned enterprise with more than 100 years experience, strict operation policy is performed, advanced processing machines guarantee the precision of all components, workers with operation license, parts get multiprocessing,transmission & electrical parts are of international famous brand. Series of test and inspection are done in the whole producing stage.
4. Will you dispatch technicians for installation and commissioning? Yes, we can, we do lots of service, please refer to our after sales part.
5. What is your advantages compared with your competitors? Quality and experience. We are the top centrifuge supplier in China, our designs and structures are similar to world famous brands.
6. Is your price competitive? Our price is not the lowest in China as for high quality, but we promise, for the same quality and collocation, our price is the most favourite, for the same price, our quality is definately superior to other brand.
7. Do you have OEM serive? Do you supply the parts? Yes, we do, as long as you provide us your drawing and detailed requirements.
8. Do you supply second hand centrifuge? No, we only provide brand new machine.
9. Do you have agent or service center in my country? We have some partnership in several countries as Indonesia, Brazil, USA, etc. Your are warmly welcomed to work as our agent. At this moment, we have no service center abroad, but we can provide overseas spot and online technical service in time.
10. How can we easily find out the most fit centrifuges? We have experienced engineer team to help you make the model selection, as long as you provide us the detailed processing material characteristics.
11. What payment mode you accept? TT, Wester Union and LC at sight.
