Surface protection,zinc plate,withe/white-blue or yellow passivated.
Left hand thread in the housing are available.
Dimensions are in mm.
Special versions upon request.
For type A and C with screw stud
type B with rivet stud.
d1
d2
l1
c
d3
d5
d6
l2
l3
l4
l5
SW
Weight
Kg/1000pcs
h9
±0.2
0.4/0
h14
h11
0/-0.4
±0.3
±0.3
±0.3
max
h14
A and C
B
8
M5
4
2
8
5
3
10.2
9
12.5
4
7
4.55
3.85
7.5
4.35
10
M6
4.5
2.2
10
6
4
12.5
11
15.5
4
8
8.50
7.10
8
7.80
13
M8
5
2.4
13
8
6
16.5
13
18.5
5.3
11
17.70
14.20
10
16.00
16
M10
6
2.7
16
10
8
20
16
23
7.3
13
35.10
23.50
M12
13
29.60
19
M14
12
3
19
14
10
28
20
28.5
10.8
16
71.20
56.20
M16
18
63.70
