Steel structure drawing warehouse price

Product Information

Product name

Steel Structure

Place of Origin

Hebei ,China(Mainland)

Wind resistance

Grade 12

Payment

 L/C,T/T, Western Union

Minimum Order

 100 Square Meters

Package

 In bulk.

Lead Time

 Within 20days after receiving the deposit.

Supply Ability

 10000000000sq /month

Material list

Project sample

Steel Structure Workshop/warehouse

Building size(m)

78 x 30 (24) x 8.5 (7) m/ Customized

Item

Specification

Main steel structure

Steel pillar

H(300-550)x200x6x10, steel Q345

Steel beam

H(300-550)x180x6x8, H300x180x6x8, steel Q345

Second steel structure

Roof purlin

C180*75*50*2.5

Wall purlin

C180*75*50*2.5

Cross support

Φ20 round steel bar, steel Q235

Column bracing

Φ20 round steel bar, steel Q235

Angle brace

L50x4 angle steel, steel Q235

Tie bar

Φ89*3, steel Q235

Roof and wall panel

Roof panel

50mm sandwich panel (EPS PU Glass wool, Rock wool)

Wall panel

50mm sandwich panel (EPS PU Glass wool Rock wool)

Rolling up door

automatic  rolling up door

Single wing door

sandwich panel door

window

Aluminum/PVC sliding window with single glass

Edge cover

steel sheet (thickness 0.5mm)

fittings

glass adhesive, self-tapping screw etc.

Other fittings

embedded

M24 steel Q235, process

Intensive  bolt

grade 10.9

Ordinary bolt

4.8S

Opinions

1) Steel Structure Building

2) Metal Building

3) Modular House

4) Steel Structure Warehouse

5) Workshop / Factory

6) Garage

7) Steel beams other riveting and welding parts

8) OEM projects

Different sizes

MOQ is 100m², width X length X eave height

Different types

Single slope ,double slope, Single span ,double-span ,Multi-span Single floors, Double floors

Cement and steel foundation bolts

Cement and steel foundation bolts

Cement and steel foundation bolts

Material Q345(S355JR) or Q235(S235JR) steel, all bolt connections. Straight cross-section or Variable cross-section.

Different bracings

X-type or V-type or other type bracing made from angle, round pipe , etc.

Different Purlins

C or Z type: Size from C120~C320, Z100~Z200

Different roof and wall panel

Single color full corrugated steel sheet 0.326~0.8mm thick, (1150mm wide), or sandwich panel with EPS, ROCK WOOL, PU etc. insulation thickness around 50mm~100mm

All accessories

Semi-transparent skylight belts, Ventilators, down pipe, galvanized gutter, etc.

Surface

Two layers of Anti-rust Paint!

Packing

Main steel frame without packing load in 40'OT, roof and wall panel load in 40'HQ!

Design Parameters

1) Live load on roof (KN/M2)

2) Wind speed (KM/H)

3) Snow load (KG/M2)  - If Applicable

4) Earthquake load - If Applicable

5) Style of Doors and Windows

6) Crane (if you have), Crane span, Crane lift height, max lift capacity, max wheel pressure and min wheel pressure

7) Size: width X length X eave height, roof slope

8) Or your idea!
