30mm dc cooling fan 30x30x10 brushless motor 5v 12v fan
- Category: >>>
- Supplier: Shenzhen Cooling Technology Co. Ltd.
Share on (62340929588):
Product Overview
Description
30mm dc cooling fan 30x30x10 12v
Product Description
| Product Name | DC Brushless Fan |
| Dimension | 30x30x10mm |
| Voltage Rated | 12V |
| Air Flow | 3.61CFM (0.102m³/min) |
| Static Pressure | 0.247 inH2O (6.28 mmH2O) |
| Bearing Type | Sleeve |
| Noise | 32.0 dB |
| Power (Watts) | 1.08W |
| RPM | 11000RPM |
| Termination | 2 Wire Leads |
| Current Rating (Amps) | 0.09A |
| Approval | CE RoHS |
Specification
| Model | Voltage | Current | Power | Speed | Air Flow | Air Pressure | Noise |
| Part No. | VDC | Amp | Watt | RPM | CFM | mmH2O | dB-A |
| CLD3010L05 | 5 | 0.14 | 0.72 | 5000 | 0.98 | 1.22 | 15.5 |
| CLD3010M05 | 5 | 0.17 | 0.84 | 7000 | 2.25 | 2.50 | 22.4 |
| CLD3010H05 | 5 | 0.19 | 0.96 | 9000 | 2.95 | 4.25 | 26.3 |
| CLD3010HH05 | 5 | 0.22 | 1.08 | 11000 | 3.61 | 6.28 | 32.0 |
| CLD3010VH05 | 5 | 0.24 | 1.2 | 13000 | 4.25 | 8.25 | 34.9 |
| CLD3010L12 | 12 | 0.06 | 0.72 | 5000 | 0.98 | 1.22 | 15.5 |
| CLD3010M12 | 12 | 0.07 | 0.84 | 7000 | 2.25 | 2.50 | 22.4 |
| CLD3010H12 | 12 | 0.08 | 0.96 | 9000 | 2.95 | 4.25 | 26.3 |
| CLD3010HH12 | 12 | 0.09 | 1.08 | 11000 | 3.61 | 6.28 | 32.0 |
| CLD3010VH12 | 12 | 0.1 | 1.2 | 13000 | 4.25 | 8.25 | 34.9 |
Product Showcase
Related Products
| 15*15*4mm | 18*18*4mm | 20*20*6mm | 20*20*10mm | 25*25*7mm | 25*25*10mm |
| 30*30*7mm | 30*30*10mm | 35*35*10mm | 40*40*7mm | 40*40*10mm | 40*40*20mm |
| 40*40*28mm | 40*40*56mm | 45*45*10mm | 50*50*10mm | 50*50*15mm | 50*50*20mm |
| 60*60*10mm | 60*60*15mm | 60*60*20mm | 60*60*25mm | 60*60*38mm | 70*70*15mm |
| 70*70*25mm | 80*80*10mm | 80*80*15mm | 80*80*20mm | 80*80*25mm | 80*80*32mm |
| 80*80*38mm | 92*92*25mm | 92*92*38mm | 120*120*25mm | 120*120*32mm | 120*120*38mm |
| 140*140*20mm | 140*140*25mm | 140*140*38mm | 150*150*50mm | 172*150*51mm | 180*180*60mm |
| 200*200*60mm | 220*60mm | 254*89mm |
