Purified Air ESP Commercial Air Eliminator Cooking Gas Extraction Extraction Kitchen Grease Absorber Electrostatic Oil Fume Purifier
- Category: >>>
- Supplier: Shanghai Fengjing Environmental Protection Equipment Co. Ltd.
Share on (62343189712):
Product Overview
Description
Product Name | Electrostatic Fume Purifier | Model | DL-GX5031 |
Brand | FENGJING | Packing | Wooden Box |
Pre-filter | S-type honeycomb filter | Input power supply | 220V 50/60Hz |
Posterior filter | Activated Carbon Particle Filter | Colour | White And Orange |
Size(L*W*H mm) | 655*627*620 | After sale service | Video Technical Support |
Equipment Resistance | <150 Pa | Adsorption Area | 10.6 m2 |
Flange DImenslon | 411*480 mm | Power(W) | 66 |
Maximum Inlet concentratlon(mg/m3 ) | 15 | Outlet Fume Concentration | <1 mg/m3 |
Number Of Machine | GX5031*1 | Number Of Electronic Cell | 1 |
Weight | 68 KG |
Product Description
SIX PRODUCT ADVANTAGES
WE PAY ATTENTION To PRACTICAL RESULTS, NEVER WORRY ABOUT EIA
Detailed Images
PREFILTER
HIGH AND LOW VOLTAGE ECTROSTATIC CELL
HIGH AND LOW VOLTAGE ECTROSTATIC CELL
REAR FILTER
Ionization segment: An electric field is formed between the high voltage ionizer and the electrode plate, which ionizes the small oil contamination and makes it charged. The stainless steel zigzag multipoint ionization structure is adopted. The front section has strong oil resistance, which makes the oil pollution not easy to encapsulate the electrodes and improves the ionization effect.
Slub casing: The sleeve used for fixing the plates effectively increases the fixed area with the plates, which makes the plates more stable, the spacing between the plates uniform, and it is not easy to fire. Material selection is aluminium alloy 6 series, which is manufactured by numerical control. The whole casing has higher corrosion resistance, higher conductivity and better ionization effect.
High voltage insulating ceramics: The safety factor of triangular insulating ceramics is stable and the electric field adsorption area is increased effectively. Isolated power supply, high temperature and high pressure resistance, help to prevent and eliminate arc, prevent oil pollution deposited on the surface of insulation layer.
Stainless steel spring handle: Electric field with stainless steel handle, easy to clean, maintain and extract, cleaning is not easy to corrode.
Stainless steel ionizer
The charged particles are adsorbed on the electrode plate, and the oil droplets are collected and flow into the recovery tank along the smooth surface of the electrode plate. The aluminum alloy material is durable and the distance between the plates is 7 mm. Using stainless steel zigzag ionizer instead of traditional tungsten wire, tungsten wire is easy to break, maintenance and replacement is frequent, and the structure of stainless steel ionizer is firm. Repeated cleaning is not easy to corrode, effectively increasing the service life of the electric field.
OPEN-DOOR POWER-OFF PROTECTION DEVICE
Certificate
Certificate Introduction
Certificate Introduction
Certificate Introduction
Packing&Shipping
Why Choose Us
Sealing Rubber Stape
Fully automatic glue sealing technology, quality starts from every detail
Fengjing environmental protection lampblack purifier seal treatment technology uses full automatic gluing technology, this technology effectively solves the oil leakage of lampblack purifier in the long-term operation process, but also prevents rain from penetrating outside the machine, effectively increasing the service life of the machine.
Company Introduction
Shanghai Fengjing Environmental Equipment Co,, Ltd, since its inception in 2008, there has always been focusing on industrial plants and catering oil smoke and other environmental pollution control. Has developed electrostatic fume purification industrial soot purifier, large exhaust gas treatment equipment other air environmental pollution control. Has developed electrostatic products. Our products are widely used in welding cutting grinding spraying, casting, chemical, wood processing,tobacco,ceramics, paper and other industries. Products have passed 1SO9001:2008 quality management system certification, China Environmental protection product certification, the European CE product safety certification.
