MM Chocolate ball making Machine chocolate bean forming machine
- Category: >>>
- Supplier: Nantong Twinkle Machinery Equipment Co. Ltd.Nantong Ltd.
Share on (62344032082):
Product Overview
Description
Product Description
M&M Chocolate ball making Machine chocolate bean forming machine
PROFILES:
Chocolate bean forming machine specially for making colorful chocolate core materials, chocolate bean. We make the relative forming mould according to the chocolate shape, such as spherical shape, button shape, olive shape, cashew shape, triangle shape.
WORKING PROCESS:
The chocolate syrup is feed from the thermal tank though pump to the mould, the mould is working under the refrigeration
situation, lowest temperature can be regulated to -28 ℃ to -30℃, it makes the liquid syrup in the mould become solid in a moment.
Then transferred to cooler of 5 ℃ to -8℃ though conveyor for further definite form.
The finalized shape enter the roller screen barrel for remove the burr of core and automatically discharged.
Chocolate bean forming machine specially for making colorful chocolate core materials, chocolate bean. We make the relative forming mould according to the chocolate shape, such as spherical shape, button shape, olive shape, cashew shape, triangle shape.
WORKING PROCESS:
The chocolate syrup is feed from the thermal tank though pump to the mould, the mould is working under the refrigeration
situation, lowest temperature can be regulated to -28 ℃ to -30℃, it makes the liquid syrup in the mould become solid in a moment.
Then transferred to cooler of 5 ℃ to -8℃ though conveyor for further definite form.
The finalized shape enter the roller screen barrel for remove the burr of core and automatically discharged.
Capacity | 100-150KG/H |
Roll speed | 0.3-1.5r/min |
Cooling roll surface temperature | -20°C |
cooling time | 18-30min |
Cooling tunnel temperature | approx. 5°C |
Total motor power | 25 KW |
Weight | 2500KG |
Dimension | 8620x1040x1840MM |
Detailed Images
Flow Chart
Our survice
Testing & training:
If the machine is exported to other countries, the buyer should be responsible for the round-air tickets, local transportation,
board & lodging.
Warranty:
The seller guarantees the quality of the products for 12 months since the date of installation. During the warranty period, any problems/defaults happen on the hard parts of the machinery, the buyer will replace the parts at the seller’s cost (FREE). If the defaults are aroused by the defaulted operations, or the buyer needs the technical assistance for the processing problems, the buyer should be responsible for all the cost and their allowance.
If the machine is exported to other countries, the buyer should be responsible for the round-air tickets, local transportation,
board & lodging.
Warranty:
The seller guarantees the quality of the products for 12 months since the date of installation. During the warranty period, any problems/defaults happen on the hard parts of the machinery, the buyer will replace the parts at the seller’s cost (FREE). If the defaults are aroused by the defaulted operations, or the buyer needs the technical assistance for the processing problems, the buyer should be responsible for all the cost and their allowance.
Certifications
Company Introduction
Nantong Twinkle Machinery Equipment Co.,Ltd is a company specialized in food machinery and related materials for candy, chocolate, biscuit , cake ects and service providers. Strict quality guarantee system and perfect management system, high-quality products and after-sales service is our foothold in this field. After years of development, the company has created a wealth of experience in sales team. All of which have helped us gain the markets in Europe, the Middle east, Africa ects.
Today’s Nantong Twinkle Machinery Equipment Co.,Ltd knows how to cherish the blessing and chance with gratitude. We take each day as a new beginning and adhere to constant struggle and innovation. Being earnest and down-to-earth as well as unremitting pursuit is our belief in entrepreneurship; quality first and reputation first is the basis for us to win the market; team-work is our reliable guarantee to build a first-class team.
Today’s Nantong Twinkle Machinery Equipment Co.,Ltd knows how to cherish the blessing and chance with gratitude. We take each day as a new beginning and adhere to constant struggle and innovation. Being earnest and down-to-earth as well as unremitting pursuit is our belief in entrepreneurship; quality first and reputation first is the basis for us to win the market; team-work is our reliable guarantee to build a first-class team.
Contact Us
Name | Ms. Annie |
Email | sales1@twinklemachine.com |
wechat | qyf881108 |
skype | yufan.qin |
whatsAPP | +86-15950886070 |
Web | www.twinklemachine.com https://twinklemachine.en.alibaba.com |
Add | 17A917 Orstar City, 100 Gongnong Rd, Nantong, China |
