Quality good suspension ball joint PI series , straight ball joint rod ends
- Category: >>>
- Supplier: Ningbo Lehonb Machinery Co. Ltd.
Share on (62344293798):
Product Overview
Description
Product Description
Ball Stud, Low carbon steel, heat treated.
Body,Low carbon steel,heat treated.
Clip,hardened spring steel.
Zinc plated, yellow dichromate
Alternative: stainless steel.
Unless otherwise specified, all dimensions are in inches.
Special request upon drawing or samples.
| Part No. | Housing Thread | Stud Thread | F | G | J | L | M | N | P |
| PI3-3 | 10-32 | 10-32 | 0.438 | 0.438 | 0.313 | 0.313 | 1.156 | 0.875 | 0.484 |
| PI3-4 | 10-32 | 1/4-28 | 0.438 | 0.563 | 0.313 | 0.313 | 1.156 | 0.875 | 0.484 |
| PI4-3 | 1/4-28 | 10-32 | 0.438 | 0.438 | 0.313 | 0.313 | 1.250 | 0.969 | 0.531 |
| PI4-4 | 1/4-28 | 1/4-28 | 0.438 | 0.563 | 0.313 | 0.313 | 1.250 | 0.969 | 0.531 |
| PI4L-4L | 1/4-28 | 1/4-28 | 0.562 | 0.500 | 0.313 | 0.340 | 1.750 | 1.500 | 1.120 |
Company Information
Other products
FAQ
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 10-30 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
