Unmanaged fast Ethernet 5 ports PoE industrial Ethernet switch for security system
- Category: >>>
- Supplier: Shenzhen I-Hirsmann Technology Co. Ltd.
Share on (62345093567):
Product Overview
Description
Products Description
Unmanaged fast Ethernet 5 ports PoE
industrial Ethernet switch for security system
Fixed Port | |
Interface | 5*10/100Base-T |
Transmission mode | Full/Half Duplex |
Power interface | Phoenix terminal, dual power supply |
LED indicators | PWR, OPT |
L2 Switching | |
Switching capacity | 1Gbps |
Packet forwarding rate | 0.744Mpps |
MAC address table | 2K |
Forwarding delay | <5us |
Buffer | 768K |
MDX/MIDX | Support |
Flow control | Support |
Jumbo frame | Support 2K Bytes |
PoE | |
PoE port | 1~4 |
PoE protocol | 802.3af,802.3at |
Pin assignment | 1,2,3,6 |
PoE mode | Standard mode |
Electrical Specifications | |
Input voltage | DC12-58V(Non-PoE), DC48~58V(PoE) |
Power consumption | <5W(Non-PoE), <125W(PoE) |
Voltage Alarm | Support |
Mechanical structure | |
Housing | Metal material |
Product size | 91X118X31mm( W*H*D) |
Weight | 0.6KG |
Mounting | DIN rail |
EMC & Ingress Protection | |
IP level | IP40 |
Surge protection of Power | IEC 61000-4-5 Level 3 (4KV/2KV)(8/20us) |
Surge protection of Ethernet port | IEC 61000-4-5 Level 3 (4KV/2KV)(10/700us) |
RS | IEC 61000-4-3 Level 3(10V/m) |
EFI | IEC 61000-4-4 Level 3(1V/2V) |
CS | IEC 61000-4-6 Level 3(10V/m) |
PFMF | IEC 61000-4-8 Level 4(30A/m) |
DIP | IEC 61000-4-11 Level 3(10V) |
EMI | CLASS A |
ESD | IEC 61000-4-2 Level 4(8K/15K) |
Free fall | 0.5m |
Environment | |
Operating temperature | -30℃~ +75℃ |
Storage temperature | -40℃~ +85℃ |
Relative humidity | 5%~95% (Non-condensing) |
Accessories | Equipment, Terminals, Instruction, Certificate, Power adapter(optional) |
Related Products
 |  |  |
| >> Ethernet Meddia Converter | >> Industrial Media Converter | >> Industrial PoE Switch |
 |  |  |
| >> Industarial Managed Switches | >> 1U Rack Managed Switch | >> Fiber Optic Equipment |
Company Information
Packaging & Shipping
Packing | Packing size | 18.5*16*6.5cm |
Net weight | 0.36KG | |
Gross weight | 0.7KG | |
Packing | Switch x1; Phoenix terminal x1; Certificate of inspection x1; Instructions&Warranty card x1 | |
Shipping | Sample order is within 2~4 days, other quantity need to be negotiated | |
Note: Power adapter and SFP transceivers are not included by default when place an order | ||
FAQ
FAQ
Q: Are you manufacturer or trading company?
A: Manufacturer, and industry network total solution provider.
Q: Do you accept ODM or OEM?
A: Yes. We provide customized service for our clients.
Q: What is your minimum order quantity?
A: MOQ is 1 PCS.
Q: What’s the payment type ?
A: T/T, L/C, Western Union, Money Cram, Credit Card, Alipay, Cash.
Q: What’s the accepted delivery terms ?
A: EXW, FOB, CIF, FAS, CIP, FCA, CPT, DED, Express Delivery.
Q: How about shipping time?
A: Within 3-15 days after receiving full payment , but if you need OEM/ODM, the shipping time depends on the specific specifications of the product.
Q: How about after-sales service?
A: We are 7*24 hours online and respond to user's field device problems in time.
Q: How about the warranty
5 years.
