Product Overview

Description



About the price
Due to the difference of models, please contact us for more detail




Product Description








Features:
*Unique Fast Release Structure.
*Suitable for Both Indoor and Outdoor Applications.
*Pipe Size Range: 12-114mm.
*Material: Galvanized Steel/EPDM Rubber (RoHs, SGS Certificated).
*Anti-Corrosion, Heat Resistance.
*Fast Delivery Time: Within 35 Days.



Product Paramenters






Part Number
Pipe Size Range(mm)
Nut  Model
Width* Thickness(mm)
400055
12-14
M8
1.5X20
400056
15-19
M8
1.5X20
400057
21-23
M8
1.5X20
400058
26-28
M8
1.5X20
400059
32-35
M8
1.5X20
400060
40-43
M8
1.5X20
400061
44-49
M8
1.5X20
400062
48-52
M8
1.5X20
589310
54-58
M8
2X20
589320
57-61
M8
2X20
400063
12-14
M8&M10
1.5X20
400064
15-19
M8&M10
1.5X20
400065
21-23
M8&M10
1.5X20
400066
26-28
M8&M10
1.5X20
400067
32-35
M8&M10
1.5X20
589349
36-39
M8&M10
1.5X20
400068
40-43
M8&M10
1.5X20
400069
44-49
M8&M10
1.5X20
400070
48-52
M8&M10
1.5X20
589350
54-58
M8&M10
2X20
400071
57-61
M8&M10
2X20
400072
63-67
M8&M10
2X20
400073
70-73
M8&M10
2X20
400074
74-80
M8&M10
2X20
400075
83-91
M8&M10
2X20
400076
101-106
M8&M10
2.5X23
400077
108-114
M8&M10
2.5X23


Includes easy closing mechanism
Combo head bolt works with slotted, hex, or Phillips drivers
Category II noise reduction according to DIN EN ISO 3822-1
Compliant for sound insulation design according to DIN 4109
Reaction-to-fire classification is "E" in compliance with DIN EN 13501-1:2010-01


Application








Recommend Products








Production Process




Packaging & Delivery




Our Certification




FAQ


1.About Price: 
Our prices are mostly based on EXW term with MOQ in normal package without marking. The price is negotiable which can be changed according to your order quantity. When you are making an inquiry, please let us know the quantity you want. 

2.About Raw Material:
Galvanized Steel, EPDM rubber (both are RoHs, SGS certificated)

3.About Sample: 
Samples are FREE, but please kindly bear the freight costs. We can help to choose the cheapest forwarder service for you. Those costs can be returned when you place the order. 

4.About MOQ: 
Our MOQ for the products are based on the mould models which can be 3,000pcs to 5,000pcs.

5.About OEM: 
Welcome, you can send your own design drawings to us, our R&D Department will give the professional advises and make it into production.

6.About Customized Logo: 
Welcome, It will be FREE for you if your order quantity for each size is more than 10,000pcs, please your own design logo CDR file to us.

7.About Quality Control:
QC Department monitors from incoming materials to every important production steps. THREE main testings will be carried out: Salt Spray Test; Torque Test; Tensile Test for loading capacity.

8.About Delivery:
Depends on the products, basically 15-35 working days after prepayment.

9.About Certifications:
ROHS, SGS,FM/UL(on Customer’s brand), we are able to acquire the certifications for your needs.

10.About Payments:
Please kindly note that our payment term is 50% prepayment before production, 50% balance payment before delivery.
