Neon power supply transformer 10kV 30mA

Share on (62349302709):


Price:RUB 1,142.64

Quantity:


Product Overview

Description

Product Description

Neon Power Supply Transformer Output:10kV 30mA 30kHz with CE

 Model: AH1-R410IL

 10kV CE.jpg





1. Compliance with EMC and LVD IEC standard, low electromagnetic disturbance;



2. Manifold protection device: open circuit, over heat;



3. High power factor: >0.9;



4. With pull-chain switch and IEC standard plug, excellent for small neon signs;

5. Use only indoor.






Model

AH1-R410IL

Input

AC220-240V 50/60Hz 0.6A

Output

10kV 30mA 30kHz

Min loading(D12mm mercury/argon)

4m

Weight

0.9kgs

Packing

20pc/carton, 20kgs/carton

Packing size(mm)

742*257*280mm

Diameter tubing(mm)

7

8

9

10

11

12

13

15

Gas pressure(mmHg)

18

17

15

13

12

11

10

9

Load length in feet(clear or red neon)

16

18

21

25

28

31

34

39

Load length in feet(mercury/argon)

18

21

25

30

33

37

40

48
