China ZKP ST/UPC FC/UPC multimode dual core fiber optic cable
- Category: >>>
- Supplier: Hunan Zhongke Optoelectronic Co. Ltd.
Share on (62351844700):
Product Overview
Description
Product Description
Features:
Price Competitive
Low Insertion Loss & Back Reflection Loss
Factory-terminated and Tested
ISO9001:2008,ROHS
Applications:
Telecom Net
Local Ring Net
Optical Fiber Sensor
Optical Fiber Test Equipment
Optical Fiber Communication System
FTTH,LAN,PON & Optical CATV.
Ordering options:
Connector type: FC, SC, LC, ST, MTRJ, MU, MPO, DIN, D4, SMA
Ferrule End-face: PC, UPC, APC
Core Type: Single-mode (SM: 9/125um), Multimode (MM: 50/125um or 62.5/125um)
Cable Quantity: Simplex, Duplex, 6cores ,12corns, 16cores, 24cores, 36cores, 48cores...
Cable Diameter: φ3.0mm,φ2.0mm, φ0.9mm
Cable Length: 1, 2, 3 meter or customized
Cable type: PVC, LSZH, OM3, OFNR, OFNP, Plenum ,Armored
specifications:
Pigtail Connector | PC (SM) | UPC (SM) | APC (SM) | MM |
Return Loss (dB) | ≥45 | ≥50 | ≥60 | ≥35 |
Insertion Loss (dB) | ≤0.2 (max≤0.3) | |||
Repeatability (dB) | ≤0.1 | |||
Durability(1/Matings) | ≥500 | |||
Operation Temperature (°C) | -25~+70 | |||
Tensile Strength (N) | ≥90 (Φ3.0), ≥70 (Φ2.0), Φ0.9 | |||
Fiber | 9/125um, 50/125um,62.5/125um,ect | |||
diameter | 0.9mm 2.0mm, 3.0mm etc | |||
Cable material | PVC, LSZH | |||
Cores | Simplex, duplex, 4cores, 6cores, 8cores, 12cores etc | |||
Detailed Images
Work shop
Company Information
Exhibition service
Packaging & Shipping
Our Services
1.Advanced production and testing equipment
2.Professional manufacturer, 100% tested
3.Full compliance with ISO 9001:2008 quality management system
4.Our company has experienced professional team
5.Provide reliable solutions and satisfactory services
6.Warmly services with careful attentions
FAQ
Q:What is the payment way for the order?
A: L/C,T/T,Western Union,MoneyGram payments for offline orders.
Q:How about your after service?
A: We will send you the component for free to replace the demaged one during the warranty time.
Q:Can i have my own customized products?
A: Yes,OEM and ODM order are very welcomed.
Q:How about the warranty?
A:3 years
Q:Why choose us?
A:We are professional manufacturers with more than 10 years experience,we have our own production factory and raw material supplier of many years cooperation.So our products have very stable quality and competitive price.
