SUNWARD SWL3230 Wheeled skid steer loader 6tons with factory price
- Category: >>>
- Supplier: Sunward Intelligent Equipment Co. Ltd.
Share on (62360174838):
Product Overview
Description
Why choose SUNWARD
1. We are a Chinese company specializing in construction machinery for more than 20 years;
2. A total of about 10,000 customers have selected SUNWARD products;
3. We have our own R&D design team and large mechanical manufacturing factory with more than 5,000 employees to serve each customer;
4. We have 200 sales and service representatives located abroad to provide localization solutions for foreign customers;
Choose SUNWARD, an international trading partner that is more suitable for you.
Welcome partners to contact us to achieve business and provide customers with better SUNWARD products.
| Model | SWL3230 | |||
|---|---|---|---|---|
| Dimension(L×B×H) | mm | 3727×1830×2068 | ||
| Working parameters | A | Maximum overall height | mm | 4020 |
| B | Height to hinge pin | mm | 3123 | |
| C | Height to top of cab | mm | 2068 | |
| D | Height to bottom of level bucket | mm | 2948 | |
| E | Length without standard bucket | mm | 2958 | |
| F | Length with sandard bucket | mm | 3727 | |
| G | Maximum dump angle | ° | 43 | |
| H | Dump height | mm | 2395 | |
| J | Dump reach | mm | 625 | |
| K | Rolback angle (bucket on ground) | ° | 30 | |
| L | Rolback angle at maximum height | ° | 93 | |
| M | Wheelbase | mm | 1148 | |
| P | Ground | mm | 205 | |
| Q | Departure angle | ° | 26 | |
| R | Turning radius from center (Coupler) | mm | 1344 | |
| S | Turning radius from center (Bucket) | mm | 2201 | |
| T | Turning radius from center (Machine rear) | mm | 1747 | |
| U | Bumper overhang behind rear axle | mm | 1170 | |
| V | Width over tire | mm | 1475 | |
| W | Bucket width | mm | 1830 | |
| Operating weight | kg | 3450 | ||
| Performance | Rated operating capacity | kg | 1100 | |
| Tipping load | kg | 2200 | ||
| Breakout force curl | kg | 2480 | ||
| Breakout force lift | kg | 2430 | ||
| Travel speed | km/h | 12.6 | ||
| Bucket capacity | m³ | 0.53 | ||
| Engine | Brand | KUBOTA | ||
| Model | V3307-CR-TE5B | |||
| Type | 4-cylinder, water cooling, diesel engine | |||
| Emission standard | EPA Tier4 / EU Stage 5 | |||
| Power | kW/rpm | 55.4/2600 | ||
| Maximum torque | N.m/rpm | 265/1600 | ||
| Electrical System | Starting motor | V/kW | 12/3.0 | |
| Generator | V/A | 12/80 | ||
| Battery | Ah | 120 | ||
| Fueling Amount | Hydraulic oil tank | L | 60 | |
| Fuel tank | L | 110 | ||
| Hydraulic System | Standard discharge | L/min | 86 | |
| Large discharge | L/min | 131 | ||
| Standard working pressure | bar | 210 | ||
| Large-discharge working pressure | bar | 165 | ||
