Form Factor | 2U, 2-socket rack server | ||||
Processors | 1 or 2 1st Generation Intel® Xeon® Scalable processors (3100/4100/5100/6100/8100 series), up to 205W 1 or 2 2nd Generation Intel® Xeon® Scalable processors (3200/4200/5200/6200/8200 series), up to 205W | ||||
Memory | 24 DDR4 DIMM slots, 2,933 MT/s; up to 12 DCPMMs, 2,666 MT/s | ||||
Internal Storage | Supports the following hard drive configuration options: * 8 x 2.5-inch SAS/SATA HDDs or SSDs * 12/16/20 x 3.5-inch SAS/SATA HDDs * 4, 8, 12, 24, or 28 NVMe SSDs * 31 x 2.5-inch SAS/SATA HDDs or SSDs Flash storage: * 2 M.2 SSDs | ||||
RAID Support | RAID 0, 1, 10, 1E, 5, 50, 6, or 60 Configured with a supercapacitor for cache power-off protection (optional) RAID level migration, drive roaming, self-diagnosis, and web-based remote configuration | ||||
Network Ports | LOM: 2 x 10 GE + 2 x GE ports Flexible NIC: 2 x GE, 4 x GE, 2 x 10 GE, 2 x 25 GE, or 1/2 x 56G FDR IB ports | ||||
PCIe Expansion | Up to 10 PCIe 3.0 slots, including 1 for a RAID controller card and 1 for a flexible NIC. | ||||
Fan Modules | 4 hot-swappable fan modules with optional N+1 redundancy | ||||
Power Supply Units | 2 hot-swappable PSUs with support for 1+1 redundancy and the following configuration options (see note 1): * 550W AC Platinum PSUs * 900W AC Platinum/Titanium PSUs * 1,500W AC Platinum PSUs * 1,500W 380V HVDC PSUs * 1,200W -48V to -60V DC PSUs | ||||
Installation suite | L-shaped guide rails, adjustable guide rails, and holding rails | ||||
Special Notices | The Titanium PSU is planned for release in Q2, 2019. |
