PICMG 1.0, PICMG 1.3, EPI 2.0, EPE standard full-size cards, Micro ATX SBC standard single boards, ATX SBC standard single boards
Support carrier board
10-slot standard PICMG 1.0 carrier boards, 14-slot standard PICMG 1.0 carrier boards, 10-slot standard PICMG 1.3 carrier boards, 13-slot standard EPI 2.0 carrier boards, 10-slot standard EPE carrier boards
I/O ports
Two front-accessible USB 2.0 ports, ATX rocker switch, reset button, power supply, HDD indicator, safety door with lock
Storage
One 5.25″ CD-ROM bay, two 3.5″ HDD bays (with shock absorption)
Operating temperature
0℃~50℃; 5%~90% (non-condensing)
Storage environment
-20℃~60℃; humidity: 5%~90% (non-condensing)
Power supply
Support standard PS2 ATX power supply
Dimensions (W×H×D)
482mm(W) x 177mm(H) x 470.4mm(D)
Order information:
4U, 19 Standard IPC-710/EC9-1501/ZX/C4580 motherboard/ZX-100S/quadruplex processor/2G memory/500G hard disk/ATX 250W power supply/CD-ROM-free/motherboard 2 network ports, 10 serial ports (6 external devices, 4 sockets), VGA+DVI-D dual-display external devices, 9 USB (2.0 external devices, 2 USB 2.0 external devices, 1 USB 3.0 external device, 4 USB 2.0 external devices 0 pin, 1 audio combination peripheral, 1 PS/2 keyboard and mouse interface peripheral, 1 LPT pin, 1 8-way GPIO pin, 1 PCIE*16 (actual speed*8), 1 PCIE*4, 2 PCI, 1 Mini_PCIE/extension.
Recommended configuration:
Megabyte core
IPC-710/EC9-1501/MW core open ZX-C-4580 four-core four-threaded processor 1.83G/2G/32G/2*LAN/10*1COM/2*PCI+2*PCI-E/1*MSATA/1*MINI-PCI-E/250W
IPC-710/EC9-1501/MW core open ZX-C-4580 four-core four-threaded processor 1.83G/4G/500G/2*LAN/10*1COM/2*PCI+2*PCI-E/1*MSATA/1*MINI-PCI-E/250W
IPC-710/EC9-1501/ZX/C4580/250W ATX
