If you are not IT expert or unfamiliar with pc installation, please buy bundle with ram at least. If buy bundle no ram, please use DDR3L-1333/1600 low voltage 1.35V Non-ECC SO-DIMM Ram. This PC DO NOT support DDR3 1.5V Ram.
What can this mini computer do?
Office work: Office, skype, yahoo, outlook and all other office requirement support and runs perfect; Design work: Photoshop, CoreIDRAW, Dreamweaver, IIIustrator, Flash, Indesign and others Game playing: support most online games and PC games, like Warcraft, Counter-Strike (CS), support 3D games but this is integrated graphic not independent cards, so don't play very high grade 3D games. Entertainment: support blue ray 1080P video play, XBMC and others
HighLight
1.Onboard Intel 2955U/3215U/I3-4020Y low power processor, the total consumption is only about 15W
2.The pc with 170*130*35MM size, Small and non-occupied, it is very convenient to carry or hanging behind the monitor
3.All aluminum alloy case, fanless heat dissipation, no noise, bring a quiet environment,Be able to work 24 hours per day.
5.Support Wake-On-Lan; Support calls on function automatically;
6.Stable: Intel SOC+Intel HD Graphics+Fanless
7.Smooth: Support 3D games and HMDI full 1080P playback
8.Strong: Work with any brand monitors; Suit for multiple application for example integrate with touch devices, industries, car repair shops, security, education, home as HTPC, business, fanancial and projects
1* SO-DDR3L SDRAM Memory Slot, Max to 8G DDR SDRAM
Storage
Support mSATA and SATA SSD; 2.5 inch laptop HDD; Can install 1pc HDD(2.5 inch) and 1pc SSD(mSATA) together
Chipset
Intel QS77 Express Chipset
BIOS
MI BIOS, ACPI supported. Support calls on function automatically
Network
Onboard RTL8111DL 10/100 / 1000Base T LAN
Audio
ALC662 chip, 6-channel sound
SATA
1 SATA3.0 interface, support for 6Gb / s; 1 SATA3 support 6Gb / s
MINI PCIE
2 MINI PCIE interface, full-height with Msata SSDs, half-height with wireless card
WiFi
150M WiFi or 300M WiFi with dual antenna(Optional)
CPU Performance
# of Cores
2
# of Threads
2
Processor Base Frequency
1.6 GHz/1.7 GHz
TDP
15 W
Lithography
22 nm
Graphics Specifications
Processor Graphics
Intel® HD Graphics
Graphics Base Frequency
200 MHz
Graphics Max Dynamic Frequency
1 GHz
I/O Ports
Display Port
1*VGA 1* HDMI
USB Port
4* USB3.0 2* USB2.0
SATA Port
1* MSATA 3.0, 6Gb/s; 1* SATA 3.0, 6Gb/s
Mini PCIE
1*MSATA SSD 1* WiFi Module
Ethernet
1 RJ45 Gigabit LAN Port
Power input port
1*DC (IN) 12V
Power and Working Environment
Input
DC100-240V AC/50-60Hz
Output
DC 12V 3A
Operating Temperature
0/70 Centigrade(32F~140F)
Storage Temperature
(-20/+80)Centigrade
Relative Humidity
10%~90%(non-condensing)
Product Dimension&Details
Noise
Fanless System
Size
17*12*3.7CM
Weight
2KG
Shell
Black Color
Package Box
Neutral Color Box or INCTEL Color Box
Content
Mini PC device, Power Adapter, Desk base, Antennas
Packing & Delivery
✈✈Actual delivery time: most customers receive within 7-15 working days. 1. All items will be double checked and well packed and they will be dispatched within 5 business days when order is paid. 2. Normally we ship package by DHL, it will take about 3~7 working days to most of countries, door to door. 3. If you address is a remote area by DHL, if you do not add remote area shipping fee, we will arrange shipment by our methods,hope you can kindly understand it, thanks. 4. e-EMS: it is for Russia and some other countries. 5.If you choose the shipping way is air post mail , it normally takes 30-90 days without tracking information , pls noticed. It's better to choose EMS or DHL , more faster and safe . 6. If you don't get the package in normal time, please contact us kindly, we will do our best to assist you. 7. If you don't accept above terms, pls do not buy it, thanks.
Company Profile
Shenzhen Inctel Technology Co.,Ltd. has established cooperation with lots of enterprises, rely on its strength, reasonable price,excellent service, over 10 years rich experience in R&D and producing. Products are popular at home and abroad. Its OEM/ODM services have already covered many countries in South East Asia, Middle East, Europe, America, South Africa etc.
1. As a professional manufacturer and supplier of mini pc over 10 years,we win our customers with good quality,best service and competitive price. 2.Our products are 100% original and have strict QC inspection before shipment. 3.Professional and efficient sales team serve for you diligently 4.Sample order is welcomed and will be delivered within 3 days. 5.We are Alibaba assessed 7 years Gold Supplier and more than 10 years industrial experience. 6.We support Trade Assurance to ensure On-time shipment and product quality. 7.We provide OEM service according to your requirements. 8.We provide 3 Years maintenance warranty for our products.
1. Can you put my brand name (logo) on these products? Yes,.We can support OEM/ODM service, the process of customization is following: 1) provide your specific requirement. 2) our design engineer draw the design draft. 3) you confirm the design draft. 4) we start produce it.
2. What payment method do you accept? T/T, Western Union, PayPal, Escrew, Alibaba Trade Assurance order payment; Money Gram, Cash, L/C, etc.
3. What is the Minimum Order Quantity (MOQ)? We can sell one piece of sample for your testing.
4. What is the lead time of your products? 1-2 days for one sample, 7-15 working days for a large quantity.
5. How many years for the product warranty? 3 years, we have a professional team work for after-sales services, please kindly feel free to contact us if any questions.
6. What are the shipping methods for it? We can ship by International express, like DHL, UPS, Fedex, TNT, etc; or by Air/ Sea, etc.
7. What kinds of customization can you do? We can do the products as per your configuration of CPU, RAM, hard disks, WiF, I/O ports, color, size, customized OS, logo, etc.
8. Can you equip the devices with related products or services? Yes, we can offer you mouse and keyboard combo, HDMI cable, genuine Windows 10 license, external CD-ROW, USB Hub, Bluetooth dongle, etc.
9. What is HS code of Partaker mini pc? 8471494000
