1.Technical Parameters of wide format laminator:
| Technical Parameters | |||||||
| Model | ADL-1600H1 (hot) | ADL-1600H5+ (hot) | ADL-1600C5+ (cold) | ||||
| Max Width | 1520mm | 1520mm | 1520mm | ||||
| Max Thickness | 25mm | 25mm | 25mm | ||||
| Speed | 0--7m/min | 0--7m/min | 0--7m/min | ||||
| Temp Range | room temp-120℃ | room temp-120℃ | room temp-60℃ | ||||
| Lifting Way | unilateral ascension | Pneumatic(air pump) | Pneumatic(air pump) | ||||
| Heating Way | infrared heating | infrared heating | infrared heating | ||||
| Preheating Time | 10-15min | 10-15min | 5-10min | ||||
| Rated Input Power | 2200W | 2200W | 1200W | ||||
| Power | 0.8-1kw/h | 0.8-1kw/h | 0.3-0.5kw/h | ||||
| Rated Input Voltage | 110/220V | 110/220V | 110/220V | ||||
| Weight | 230/180kg | 255/205kg | 215/165kg | ||||
| Packing Size | 215*80*74cm(1.273m3) | 215*80*74cm(1.273m3) | 215*80*74cm(1.273m3) | ||||
2.Performance of wide format laminator:
1) Multifunction laminating,low cost laminating,High speed laminating.
2) Intelligence control the laminating speed,make it 7m/min,laminating material profectly and efficient
3)Intelligent infrared checking system protect the safety of laber and the roller.
4) Automatic cutting system,advanved anti-skew,three cut knife,saving your cost.
5)Rolling up the back paper automatically.
3.Application of wide format laminator:
Laminator is used for surface post processing on Spray painting, graphic printout, photo studio, printing industry, building materials industry,etc. fields. It is developed as a easy to use, energy-saving, low-cost laminator.
Laminate the film on the surface of the material. It’s a good protection for the materials and images. So the materials could not be scratched and damaged. When using the cold function, please use the cold film.







1.Can I get a free sample for a testing?
A. Sure, you can send us the material you want to print, we will test it for you and take photos and videos for your reference, if you want to see it, just pay the shipping cost is ok.
2.How long warranty period you provide for your products?
A. All machine of us have 12months warranty from the day you begin use the machine.
3.Do you have all consumables for your machine?
A. Yes, all consumables of our machine is avaliable, just contact us and tell us your requirement.
4.Can I install the machine easily?
A. Yes, the machine support all kinds of operate system, and there is CD and manual matched during paking, you can see the CD install by yourself. Also you can ask us for help, we will use teamviewer assist you online on problem.
5.How to buy your machine?
A. You can place Protection Order on Alibaba directly, or let us know the detailed you need, we will make proforma invoice with our bank information for you confirm, and we will delivery the goods accordingly after get payment, and let you know the tracking number(or send you B/L) then.
6.Do you take part in the exhibition?
A. Yes, we take part in exhibition in Shanghai, Guangzhou each year, and we will send email to inform you some days in advance, and welcome to our booth in that time.


Welcome to your inquiry about wide format laminator ,further information,pls contact us freely,thanks!
