MXH16 Stoke 5 10 15 20 25 30 40 50 60mm Slide Pneumatic Air Cylinder
- Category: >>>
- Supplier: Shanghai Ruan Long Industrial Automation Appliance Co. Ltd.
Share on (62366218084):
Product Overview
Description
Product Description
1. Do not place your fingers in the clearance between the non-ro- tating plate and the cylinder tube. Your fingers could get
caughtbetween the table and the cylinder tube when the piston rod re-tracts. If fingers are caught in a cylinder, there is a
danger of in-jury due to the strong cylinder output, and therefore cautionmust be exercised.
2. In terms of the load mass and moment, the cylinder must be op-erated below the maximum load mass and allowable moment.
3. If the output of the compact slide is applied directly to the table,make sure it is applied along the rod axial line. (Refer to
thefigure below.)
caughtbetween the table and the cylinder tube when the piston rod re-tracts. If fingers are caught in a cylinder, there is a
danger of in-jury due to the strong cylinder output, and therefore cautionmust be exercised.
2. In terms of the load mass and moment, the cylinder must be op-erated below the maximum load mass and allowable moment.
3. If the output of the compact slide is applied directly to the table,make sure it is applied along the rod axial line. (Refer to
thefigure below.)
Recommend Products
\t\t\t\t\t\t\t\t\tOur Service \t\t\t\t\t\t\t
our company
Founded in January 2002,Shanghai RuanLong Industrial Automation Electric Appliance Co., LTD., is located in Shanghai Songjiang Dongjing industrial park. We mainly produce and sell pneumatic components,hydraulic components,transmission components, valves, hardware and electromechanical components.With a wide range, reliable quality and reasonable price, our products are widely applied in many mechanical equipments.We have been widely recognized by customers in China with a perfect sales network and stable client groups. With a professional sales team of organization skills, the company is also a provider of industrial products which centralized purchases China industrial products and service for you.Looking forward to the future industrial market, we hope to work hand in hand with you.
\t\t\t\t\t\t\t\t\tPackaging & Shipping \t\t\t\t\t\t\t
\t\t\t\t\t\t\t\t\tFAQ \t\t\t\t\t\t\t
1.Q:What's your main products?
A:We mainly produce Pneumatic components, Hydraulic components,Linear Guides and Pneumatic valves and fittings.
2.Q:Is sample order acceptable?
A:Yes, it's ok.
3.Q:How to place the order?
A:You can send us email or inquiry at Alibaba directly
4.Q:How many days for deliver?
A:Generally it's 5-10 days if the goods are in stock.
5.Q:How to make the payment?
A:We accept Bank T/T, L/C, D/A, D/P.
6.Q:How will you make the shipment
A: By sea shipment/Air/Express service.
MXH16 Stoke 5 10 15 20 25 30 40 50 60mm Slide Pneumatic Air Cylinder
MXH16 Stoke 5 10 15 20 25 30 40 50 60mm Slide Pneumatic Air Cylinder
MXH16 Stoke 5 10 15 20 25 30 40 50 60mm Slide Pneumatic Air Cylinder
