Led bulb glue dispensing machine Rotary Table dispenser automatic circular UV glue dispensing machine TH 2004L1 KJ
- Category: >>>
- Supplier: Cixi Tianhao Electric Technic Co. Ltd.
Share on (62370679279):
Product Overview
Description
Product Description
Features
Rotary Table dispenser automatic circular dispensing machine TH-2004L1-KJ
Product introduction
TH-2004L1-KJ rotary table provides an efficient method of dispensing a circular pattern on areas that are difficult to access. Widely used in energy industry saving lamps,Speaker motors, end caps, oil seals, bearings, panels, etc.Rotary Table Benchtop Robot for dispensing beads on circular parts up to 15" in diameter.
Function
TH-2004L1-K Jrotary table provides an efficient method of dispensing a circular pattern on areas that are difficult to access.
Liquid Materials
UV adhesive, glue, cyanoacrylate,oil
Features
1.Fully programmable for accurate dispensing beads on circular parts up to 15" in diameter.
2.fully adjustable in rotation speed, circle diameter and dispensing time. Dispense from valves mounted on the Z-axis.
3.The system is fully programmable to control dispense delay, degree of rotation, and wait period before cycling.
4.Universal adjusting device.Also machine can coating inside on circle product.
5.Precision suck-back valve.close glue quickly,ensures no dripping.
6.Feed system of 304 s/s 1liter tank.
2.fully adjustable in rotation speed, circle diameter and dispensing time. Dispense from valves mounted on the Z-axis.
3.The system is fully programmable to control dispense delay, degree of rotation, and wait period before cycling.
4.Universal adjusting device.Also machine can coating inside on circle product.
5.Precision suck-back valve.close glue quickly,ensures no dripping.
6.Feed system of 304 s/s 1liter tank.
service Free
Help you seek the glue.
Free offer trial video for your sample.
Free training with machine.
Free offer accessories dispensing kit.
Save cost
One machine instead of three or four staff, reduce the
management cost, also can work for 24 hours.
Help your business
You can bring customers to visit your workshop,the equipment to produce customer
satisfaction products,then take good business for you
Specification
| ITEM | TH-2004L1-KJ |
| Standard | CE Approved |
| Max Working diameter | ¢200 |
| XY/Z Speed | 800/350 mm/Axis |
| Vertical travel | 50 mm (other lengths optional) |
| Rotation speed: | 10~300 Cycles/minute |
| Drive | Precision step motor |
| Control way | Micro Master |
| Repeatability | ±0.01mm |
| Frequency | >100time/munite |
| Adjusting way: | universal adjustment of frame |
| Input Air pressure | (1bar =1.01972kg/cm² =14.5038psi) |
| Input voltage | 110/220VAC |
| Output voltage | 24VDC |
| Temperature: | 5°C to 45°C (41°F-113°F) |
| Humidity | 85% RH at 30°C non-condensing |
| size | 390 x 360 x 340(mm) |
| Weight | 10KG |
More Product
Desktop robotic hot glue dispenser dispensing robot
manual dispensing machine for epoxy resin
silicone dispenser dispensing machine system
Robotic Dispensing Machine Glue Dispenser Robot With Vison Systems.
xyz axis dispenser robot for Adhesive,Adhesive Glue,Epoxy Glue For Pcb.
Desktop dispensing robots,glue liquid dispensing machine TH-2004D-300R.
Company Information
| Company Name: | |
| ADD: | NO.789 Huchong Road cixi city zhejing china |
| Factory established time: | Augest.8.2001 |
| Time of exports trades: | Jan.1.2006 |
| Export right: | Have oneself right of import and export offer certificate of origin |
Certifications
Exhibition
Packing & Delivery
| Packaging | |
| Packaging Details | The normal package is carton(Size: L*W*H). If container is too tigher,we will use pe film for packing or wooden box pack it according to customers special request. |
