Water-cooled triode RS3021CJ 20KW Oscillation Tube


The China made RS3021CJ electronic tube is coaxial with a cermet structure power transistor and its cooling method is water cooling. The maximum operating frequency is 120MHz, the maximum anode dissipation power is 10kW, and the maximum oscillating power of the anode is up to 20kW. This tube type is mainly used for Class B RF amplifiers or industrial high-frequency heating equipment.



Filament Voltage
5.7V
Filament Current
135A
Plate Dissipation
10KW
Maximum operating frequency
120MHz
Cooling
Forced Water




General Discreption




The electron tube is a device that controls electric current flow in a high vacuum between electrodes to which an electric potential difference has been applied. The type known as a thermionic tube or thermionic valve uses the phenomenon of thermionic emission of electrons from a heated cathode and is used for a number of fundamental electronic functions such as signal amplification and current rectification.



Hot Products PN


4CX15,000R
3CX3000A1/8238
4CX250B/7203
4CW100,000E
3CW45,000H3
ML-5681K
8560AS
3CX3000F1/8239
4CX5000A
4CW150,000E
3CW5000A3
ML-5682K
4CX20,000B
4CX20,000D/9015
4CW10,000B
4CW25,000A
3CW5000F3
ML-6420
4CX20,000C
3CX1500C7/8938
4CW25,000A
4CW250,000B
3CX1500D7
ML-6421F
3CX10,000U7
3CW7000H3/Y-842A
4CW50,000E
4CX10,000D
3CW1750A7
ML-6422
4CX20,000E
3CX400A7/8874
4CPL1000C
4CX15,000A
3CW20,000H7
ML-6423F
4CX25,000C
3CX2500A3/8161
9019/YC-130
4CX1500A
3CW2000A7
ML-6424


Main Applications




The electron vacuum power tubes are mainly used for broadcast, communications, radar, industrial heating, semiconductor processing, science and medical applications as below

• Induction and dielectric heating
• Steel pipe production
• X-ray spectroscopy
• Television transmission
• Radio transmitter

• High Frequency Cylinder Welding
• High-frequency heating
• Vacuum tube amplifier
• Radar scanning
• Radio communications

• Plastic & textile Processing
• Linear accelerator
• RF radio broadcasting
• MRI medical systems
• Semiconductor processing



Packing




Our Company


Cixi AnXon Electronic Co., Ltd

The company designs and produces power tubes for broadcast, communications, radar, industrial heating, semiconductor processing, science and medical applications, with customers located in virtually every country in the world.
The products are used for top China Natioal projects, such as launch vehicles, Communications satellites, Linear accelerator, SARFT Radio and TV Covering.
