Product Overview
Description
Products Description
PerMix Advantages & Services: | ||||||||
● PerMix machines are designed and manufactured as “tailor-made” ones to meet our customers’ individual requirement. | ||||||||
● Since 1954, PerMix has been building our know-how in mixing and processing with our design team located in both Israel and China. | ||||||||
● PerMix has been setting up a global network of agents and representatives to serve our worldwide customers locally and on time. | ||||||||
● PerMix has a lot of experience to sub-contract mixers for well-known equipment suppliers in Europe and USA, and we build the machines to fulfil the highest standard. | ||||||||
● PerMix has its workshop located in Shanghai area, China; where there is a complete and endless production capability at a reasonable price. | ||||||||
● PerMix mixers price is competitive compared with the quality of the same level. | ||||||||
● PerMix offers a comprehensive range of industrial mixing equipment in the market. | ||||||||
● Applications of PerMix industrial mixers cover wherever there is a need for mixing, including but not limited to chemicals, food, cosmetics, rubber, plastics, pharmaceuticals. | ||||||||
INTRODUCTION:
PerMix PS series Bottom Entry Mixer is a high shear mixer for batch operation. When you want to produce stable emulsions and creams, wet and dissolve sticky powder (gums, thickeners, stabilizers), deagglomerate and disperse micro-phase solid ingredient (silicon dioxide, bentonite, titanium dioxide) into liquid without fish-eyes, or other similar tricky tasks, a traditional agitator is usually not able to achieve the expectation. However, the PerMix PS series Bottom Entry Mixer is what you should choose to do the job.
WORKING PRINCIPLES:
PerMix PS series Bottom Entry Mixers work with a special designed stator/rotor working head. When it works, this stator/rotor head is able to draw the solids and liquids around it into its center, and then push them radially through the stator openings back to the tank. During this period, the solids and liquids are subject to an action of milling and shearing which is so intensive that they are deagglomerated, homogenized and dispersed into each other even though they are immiscible by traditional agitation.
INSTALLATION AND SET-UP:
In the Batch process, the mixer is immersed into the liquid. There are many installation methods for the PS series Bottom Entry Mixers. It can be lifted up by a lifting stand (hydraulic or electric), or it can be installed with flange on the top of a tank, or from its side, or at its bottom. For the vacuum or pressurized tank, the mixer must be equipped with a mechanical shaft sealing.
SPECIFICATION:
Top Entry Mixer:
Model | Watts, kW | RPM, @50Hz | Max. Capacity, L | Shaft Length, mm | ||
@1 cPs | @3,000 cPs | |||||
PS-X/080 | 1.5 | 3000 | 50 | 20 | 350 | |
PS-X/100 | 2.2 | 100 | 50 | 600 | ||
PS-X/120 | 4 | 300 | 150 | 700 | ||
PS-X/140 | 7.5 | 800 | 500 | 800 | ||
PS-X/160 | 11 | 1500 | 750 | 820 | ||
PS-X/180 | 18.5 | 2000 | 1000 | 1100 | ||
PS-X/200 | 22 | 1500 | 4000 | 2000 | 1150 | |
PS-X/220 | 30 | 5000 | 2500 | 1200 | ||
PS-X/240 | 37 | 6500 | 3200 | 1300 | ||
PS-X/270 | 55 | 10000 | 5000 | 1500 | ||
PS-X/290 | 75 | 12000 | 6000 | 1550 | ||
PS-X/300 | 90 | 15000 | 7500 | 1600 | ||
1) PS-C, PS-D, PS-M share the same specifications.
2) Actual liquid capacity will vary depending on the liquid type and different stator rotor system.
3) PerMix offers bigger capacity according to customer requests.
4) PerMix reserves the right to modify the design without notice.
2) Actual liquid capacity will vary depending on the liquid type and different stator rotor system.
3) PerMix offers bigger capacity according to customer requests.
4) PerMix reserves the right to modify the design without notice.
Bottom Entry Mixer:
Model | Watts, kW | RPM, @50Hz | Max. Capacity, L | Shaft Length, mm | ||
@1 cPs | @3,000 cPs | |||||
PS-B/80 | 1.5 | 3000 | 50 | 20 | 80 | |
PS-B/100 | 2.2 | 100 | 50 | 100 | ||
PS-B/120 | 4 | 300 | 150 | 150 | ||
PS-B/140 | 7.5 | 1000 | 500 | 150 | ||
PS-B/160 | 11 | 1500 | 750 | 150 | ||
PS-B/180 | 18.5 | 2000 | 1000 | 180 | ||
PS-B/200 | 22 | 4000 | 2000 | 180 | ||
PS-B/220 | 30 | 5000 | 2500 | 190 | ||
PS-B/240 | 37 | 1500 | 6500 | 3200 | 200 | |
PS-B/270 | 55 | 10000 | 5000 | 210 | ||
PS-B/290 | 75 | 12000 | 6000 | 210 | ||
1) Actual liquid capacity will vary depending on the liquid type and different stator rotor system.
2) PerMix offers bigger capacity according to customer requests.
3) PerMix reserves the right to modify the design without notice.
2) PerMix offers bigger capacity according to customer requests.
3) PerMix reserves the right to modify the design without notice.
Applications:
a.Food & Beverage
Reconstituted milk, Salad dressing, Mayonnaise, Ice cream, Cheese, Yogurt, Fruit juice
b.Pharmaceutics & Biology
Drug synthesis, Vaccine, Fat emulsion, Injectable suspension, Veterinary medicine, Cell extraction
c.Cosmetics & Daily Care
Detergent, Body gel, Shampoo, Cream, Lotion, Tooth paste, Soap
Reconstituted milk, Salad dressing, Mayonnaise, Ice cream, Cheese, Yogurt, Fruit juice
b.Pharmaceutics & Biology
Drug synthesis, Vaccine, Fat emulsion, Injectable suspension, Veterinary medicine, Cell extraction
c.Cosmetics & Daily Care
Detergent, Body gel, Shampoo, Cream, Lotion, Tooth paste, Soap
Product Details
More Products
Our Advantage
Company Information
Our Customers
Packaging & Shipping
FAQ
Q: What is your price level compared with European suppliers and local Chinese suppliers?
A: Depending on the machine type and size, our price level is 30%-60% less than the European suppliers and 5-15% higher than the big local suppliers.
Q: Are you able to provide tailor-made design and production for the mixers?
A: Yes, in fact more than half of our mixers are tailor made, which is one of our strong points.
Q: Are you able to design and produce other processing equipment?
A: We are open to discuss about it.
Q: Can you provide machines to OEM customers, meaning to label their brands on the machines.
A: Yes we are doing it a lot. We have several OEM partners in the USA.
Q: Do you have agent network out of China?
A: Yes we do have agents but only in some countries, for example in USA, Germany, Poland, Spain, Denmark, Turkey, Argentina, etc.We are still looking for more agents because we believe to work with agents is the best way to do business.
Q: What is your delivery lead time of the mixing equipment.
A: Depending on the size and level of customization, but usually it is from 6-14 weeks.
Q: How do you pack and ship the mixing machines?
A: For machines don't require full container loading, we will pack them in wooden case. For FCL (full container loading) shipment,we will just wrap the machines in plastic films and fix them in the container. The shipment can be either by air or by sea.
A: Depending on the machine type and size, our price level is 30%-60% less than the European suppliers and 5-15% higher than the big local suppliers.
Q: Are you able to provide tailor-made design and production for the mixers?
A: Yes, in fact more than half of our mixers are tailor made, which is one of our strong points.
Q: Are you able to design and produce other processing equipment?
A: We are open to discuss about it.
Q: Can you provide machines to OEM customers, meaning to label their brands on the machines.
A: Yes we are doing it a lot. We have several OEM partners in the USA.
Q: Do you have agent network out of China?
A: Yes we do have agents but only in some countries, for example in USA, Germany, Poland, Spain, Denmark, Turkey, Argentina, etc.We are still looking for more agents because we believe to work with agents is the best way to do business.
Q: What is your delivery lead time of the mixing equipment.
A: Depending on the size and level of customization, but usually it is from 6-14 weeks.
Q: How do you pack and ship the mixing machines?
A: For machines don't require full container loading, we will pack them in wooden case. For FCL (full container loading) shipment,we will just wrap the machines in plastic films and fix them in the container. The shipment can be either by air or by sea.
