Rtelligent Nema 34 Closed Loop Stepper Motor Driver Kit 12NM 6A Hybrid Stepping 172mm Motor Length Micro Digital 100V DC 80V AC
Rtelligent Nema 34 Closed Loop Stepper Motor Driver Kit 12NM 6A Hybrid Stepping 172mm Motor Length Micro Digital 100V DC 80V AC
Rtelligent Nema 34 Closed Loop Stepper Motor Driver Kit 12NM 6A Hybrid Stepping 172mm Motor Length Micro Digital 100V DC 80V AC
Rtelligent Nema 34 Closed Loop Stepper Motor Driver Kit 12NM 6A Hybrid Stepping 172mm Motor Length Micro Digital 100V DC 80V AC
Rtelligent Nema 34 Closed Loop Stepper Motor Driver Kit 12NM 6A Hybrid Stepping 172mm Motor Length Micro Digital 100V DC 80V AC
Rtelligent Nema 34 Closed Loop Stepper Motor Driver Kit 12NM 6A Hybrid Stepping 172mm Motor Length Micro Digital 100V DC 80V AC
Rtelligent Nema 34 Closed Loop Stepper Motor Driver Kit 12NM 6A Hybrid Stepping 172mm Motor Length Micro Digital 100V DC 80V AC

Rtelligent Nema 34 Closed Loop Stepper Motor Driver Kit 12NM 6A Hybrid Stepping 172mm Motor Length Micro Digital 100V DC 80V AC

Share on (62372179355):


Price:$129.50 - $138.00

Quantity:


Product Overview

Description



Rtelligent Nema 34 Closed Loop Stepper Motor Driver Kit 12NM 6A Hybrid Stepping 172mm Motor Length Micro Digital 100V DC 80V AC

My dear customer,
Thank you for visiting our product.
Hope our products could satisfy your need.

If you need any help, or want something special products, pls don't hesitate to contact me.
We will try our best to help you!

Now pls see the details of the stepper motor and driver kit.


Product Description


1. Technical specification

Phase number: 2

Step angle: 1.8 degree

Holding torque: 12NM

Rated current: 6.0A

Phase inductance: 8.6mH

Phase resistance: 0.73Ohm

Rotor inertia: 4000g.cm2

Encoder resolution: 1000

Shaft diameter: 14mm

Motor body length: 172mm

2. General specification

Step accuracy: ±5%(synchronizing, no-load)

Temperature rise: 80 degrees centigrade Max

Ambient temperature: -10 degrees centigrade —+50 degrees centigrade

Insulation resistance: 100MΩmin.500VDC

Voltage resistance: 500VAC for one minute

Radial runout: 0.06Max.(450g-load)

Axial runout: 0.08Max.(450g-load)
