Specifications： 1. The machine has Chinese and English operation interface. It's easy for you to learn and undstand. Its operation setting is simple and practical. 2. The machine runs very smoothly and very noisily at high speed ,which greatly increases the stability and motion accuracy of the equipment. 3. The functions of the software has regionalarray,translation,rotation and so on. 4. The equipment can support CAD format, PLT format, DXF file, G code import. 5. The machine is equipped with the needle control button, no need for external teaching device, more convenient than similar products debugging.
Product Paramenters
Model
ARW-300B
Working range X/Y(mm)
300*300
Working range Z(mm)
100
Max load X/Y/Z(kg)
8/8/5
Moving speed X/Y/Z(mm/S)
0~500/350
Repositioning accuracy
±0.02
Program capacity
100 programs, 4000 points for each program. (can be copied from U disk)
Edit mode
Hand held teaching programmer
I/O Signal
4Inpus/4Outputs
Interpolation function
3-Axis (all lines of 3D cubical space are adapted)
Drive mode
Synchronous belt and Precision linear dual-rail
Working humidity
20%～90% non condensing
Recommend Products
Company Profile
FAQ
Q: What is the bulk order delivery time? A: Order lead time will be 2-10 working days, depend on product you order. Q: How about the package? A: Foam and wooden case to protect products. Q: Warranty and after sales service？ A: One-year warranty free for spare parts, Whole life technical support. Q: Do you test all your goods before delivery? A: Yes, we have 100% test before delivery. Q: Where is your company located? A: Our company is located in Kunshan city, Suzhou city, Jiangsu province.
