Eps Vacuum Foaming Take Away Plate Machine For Producing Styrofoam
- Category: >>>
- Supplier: Hangzhou Sutuan Machinery Co. Ltd.
Share on (62375657371):
Product Overview
Description
Product Information
Machine Type | One-Touch Mould Change Series EPS Shape Moulding Machine | ||||||||
Model | ST1214SQW | ST1417SQW | ST1915SQW | ||||||
Data | unit | ||||||||
Overall | mm | 5363*3310*4852 | 5363*3610*5152 | 5363*3710*5352 | |||||
Mould size | mm | 800*1300 | 1200*1400 | 1500*1900 | |||||
Product high | mm | 350 | 350 | 350 | |||||
Move Distance | mm | 1200 | 1200 | 1200 | |||||
Rod | Diameter | mm | 80 | 80 | 100 | ||||
Quantity | pcs | 4 | 4 | 4 | |||||
Oil | Diameter | mm | 125 | 150 | 150 | ||||
Distance | mm | 1200 | 1200 | 1200 | |||||
Force | bar | 29437 | 42390 | 42390 | |||||
Hopper | Capacity | L | 145 | 145 | 145 | ||||
Quantity | pcs | 2 | 2 | 2 | |||||
Steam | Machine Inlet | DN | 100 | 100 | 100 | ||||
Mould Inlet | DN | 50*2 | 50*2 | 50*2 | |||||
Pressure | bar | 6 | 6 | 6 | |||||
Consumption | Kg | 4~5 | 4~5 | 4~5 | |||||
Cooling | Machine Inlet | DN | 80 | 80 | 80 | ||||
Mould Inlet | DN | 50 | 50 | 50 | |||||
Pressure | bar | 4 | 4 | 4 | |||||
Consumption | Kg | 0~6.28 | 0~6.28 | 0~6.28 | |||||
Vacuum | Connector | 100 | 100 | 100 | |||||
Drainage | L/h | 100 | 100 | 100 | |||||
Air | Low | DN | 65 | 65 | 65 | ||||
bar | 4 | 4 | 4 | ||||||
High | DN | 50 | 50 | 50 | |||||
bar | 6 | 6 | 6 | ||||||
Consumption | m³ | 0.3~0.6 | 0.3~0.6 | 0.3~0.6 | |||||
Hydraulic | Motor | Kw | 7.5 | 11 | 11 | ||||
Capacity | L | 400 | 400 | 400 | |||||
