Hot Sale High Quality Austenitic Seamless Stainless Steel 904L N08904 1.4539 plate sheet coil strip manufacturer
- Category: >>>
- Supplier: Zhengzhou Huitong Pipe Fittings Co. Ltd.
Share on (62377371110):
Product Overview
Description
Venta caliente de alta calidad de acero inoxidable sin costura 904L N08904 1.4539 fabricante de tiras de bobina de de placa
Stainless Steel 904L Plates and Stainless Steel 904L Sheets
Stainless Steel 904L Plates Specification
| Specifications | : | ASTM B677 / B673 / B674, ASTM A240, ASTM A240M, ASTM A480, ASTM A480M, ASTM B625 / ASME SB625 |
| Dimensions | : | ASTM, ASME and API |
| Size | : | 1000 mm x 2000mm, 1220mm x 2440mm, 4′ x 8′, 1250mm x 2500mm, 1500mm x 3000mm to 6000mm, 2000mm x 4000mm to 6000mm |
| Range | : | 5mm To 150mm |
| Condition | : | Cold Drawn & Polished Cold Drawn, Centreless Ground & Polished |
| Specialize | : | Shim Sheet, Perforated Sheet, B. Q. Profile. |
| Hardness | : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Thickness | : | 4.0mm – 100mm |
| Form | : | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) |
| End | : | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
904L Stainless Steel Plates & Stainless Steel 904L Sheets Equivalent Grades
| STANDARD | WERKSTOFF NR. | UNS | JIS | AFNOR | BS | KS | EN |
| SS 904L | 1.4539 | N08904 | SUS 890L | Z2 NCDU 25-20 | 904S13 | STS 317J5L | X1NiCrMoCu25-20-5 |
Production according to national and international standards (e.g. ASME, ASTM, API, EN, DNV, etc.)
Chemical Composition Of Stainless Steel 904L Plates & Stainless Steel 904L Sheets(UNS N08904 Plates)
| Grade | C | Mn | Si | P | S | Cr | MO | Ni | CU | |
| 904L | Min | – | – | – | – | – | 19.0 | 4.00 | 23.00 | 1.00 |
| max | 0.20 | 2.00 | 1.00 | 0.045 | 0.035 | 23.0 | 5.00 | 28.00 | 2.00 |
Mechanical properties Of SS 904L Plates (UNS N08904 Plates):
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
| Rockwell B (HR B) | Brinell (HB) | ||||
| 904L | 490 | 220 | 35 | 70-90 typical | – |
Rockwell Hardness value range is typical only; other values are specified limits.
Physical properties Of SS 904L Plates & Stainless Steel 904L Sheets(UNS N08904 Plates)
Grade | Density (kg/m3) | Elastic Modulus (GPa) | Mean Co-eff of Thermal Expansion (µm/m/°C) | Thermal Conductivity (W/m.K) | Specific Heat 0-100°C (J/kg.K) | Elec Resistivity (nΩ.m) | |||
| 0-100°C | 0-315°C | 0-538°C | At 20°C | At 500°C | |||||
| 904L | 8000 | 200 | 15 | – | – | 13 | – | 500 | 850 |
Grade Specification Of Stainless Steel 904L Plates & Stainless Steel 904L Sheets(UNS N08904 Plates)
| Grade | UNS No | Old British | Euronorm | Swedish SS | Japanese JIS | ||
| BS | En | No | Name | ||||
| 904L | N08904 | 904S13 | – | 1.4539 | X1NiCrMoCuN25-20-5 | 2562 | |
FAQ
FAQ:
Q:How does your factory do regarding quality control?
A:Quality is priority. we always attach great importance to quality controlling from the beginning to the end.
Mill Test Certificate is supplied with shipment. If needed, a Third Party Inspection is acceptable.
Q:May I have some samples before bulk order?
A:Yes, of course. samples are free but you have to pay the courier.
Q:Can we visit your Company?
A:Surely. Welcome to China and we will be honored to have a customer and friend.
Q:What is the payment terms?
A:T/T, L/C ,Western Union,etc.
Q:What's your delivery time?
A:For stocks, we can send the goods to loading port within 7 days after receiving your deposit.
For production period, it usually needs about 10days- 60days after receiving the deposit.
Q:Is it OK to mark my logo on your products?
A:Yes. OEM and ODM are available for us.
