1GE onu gpon ZTE chip ftth fttx dual model 1 port ONU XPON Router

Product Overview

Description

1GE onu gpon ZTE chip ftth fttx dual model 1 port ONU XPON Router











 1. Features (1GE onu gpon ZTE chip ftth fttx routing dual model 1 port ONU XPON Router)

Ø HGU ONU with ZTE chip

Ø Compatible with popular GPON and EPON OLT

Ø Bridging and routing modes can be set

Ø Support loop detection, IGMP snooping

Ø 802.1Q VLAN, QoS for priority of service

Ø Support port speed, storm suppression

Ø Support Telnet, CLI, OAM and Web management

Ø Support NAT, Firewall

Ø Support remote software upgrading

   2. Overview (1GE onu gpon ZTE chip ftth fttx dual model 1 port ONU XPON Router)

FIBERWAY PTF2351E is 1GE XPON(GPON and EPON dual mode) HGU ONU. It is designed to meet the multi-service needs of fixed network operators or cable operators. It is widely used in FTTO (office), FTTD (desk), FTTH (home) broadband access, video surveillance and other requirements. It is based on mature Gigabit XPON technology. it has high stable performance, cost-effective, high reliability, easy management, configuration flexibility and good quality of service (QoS) guarantees. It is fully compliant with XPON technical requirement, such as IEEE802.3ah technical standards.

It can also be applied to a wide temperature environment, and also has a firewall function.





   3. Parameters (1GE onu gpon ZTE chip ftth fttx dual model 1 port ONU XPON Router)



Items	Unit	Specifications
PON
PON standard		EPON IEEE802.3ah, GPON ITU-T G.984.x
Optical interface		SC/PC connector,1 XPON interface(EPON PX20+ and GPON Class B+) Receiving sensitivity: ≤-27dBm Transmitting optical power: 0 ~ +4dBm Transmission distance: 20KM
Speed	Gbps	GPON: uplink 1.25Gbps, downlink 2.5Gbps; EPON: symmetric 1.25Gbps
Wavelength	nm	Tx1310, Rx 1490
Interface	data	1GE 10/100/1000Mbps Auto adaptive Ethernet interfaces, Full/Half Duplex,  RJ45 connectors
Indicator	LED	POWER, PON, LOS, LAN
Operating condition	℃	Operating temperature: -5 ~ +55
Storing condition	℃	Storing temperature: -30 ~ +60
Humidity	%	10~90(non-condensing)
Power supply	V	DC 12V,0.5A adapter
Power consumption	W	≤4
Dimension	mm	112×83×19(L×W×H)
Net weight	Kg	0.11
