dj lights led bar DMX 512 pixel wash bar 1200w STROBE led dj strong strobe light LED Pixel Effect Panel
- Category: >>>
- Supplier: Guangzhou Anmingli Stage Lighting Manufacturer
Share on (62379204445):
Product Overview
Description
Product Description
AL-005IP
Waterproof LED Pixel Mapping Strobe Bar DJ Stage Equipment
ELECTRICAL
• Power Supply: 100-240V – 50/60Hz
• Power Consumption (at 230V):Strobe: 1200 W Static:950 W
• Power Consumption (at 120V):Strobe: 1200 W Static: 850 W
• Output (at 230V):3 units on a single power line
• Output (at 120V):2 units on a single power line
• Power Supply: 100-240V – 50/60Hz
• Power Consumption (at 230V):Strobe: 1200 W Static:950 W
• Power Consumption (at 120V):Strobe: 1200 W Static: 850 W
• Output (at 230V):3 units on a single power line
• Output (at 120V):2 units on a single power line
SPECIFICATIONS | ||||||||
Source | 512Pcs*1.5W RGB Leds + 512Pcs*0.5WWhite Leds | |||||||
CT:W | 6250 K | |||||||
Strobe without lens (peak) 136’000 lm; Static ON without lens 28’834; Strobe with lens (peak) 46’200; Static ON with lens 27’188 lm | ||||||||
Source Life Expectancy | >30.000 h | |||||||
• Lux:(120°) 1139 lux, (60°) 4152 lux @3m Full • Lux:(120°) 410.1 lux, (60°) 1495 lux @5m Full | ||||||||
BeamAngle:without lens 120°, with lens 60 ° | ||||||||
CONTROL | ||||||||
Protocols | DMX512, RDM,Art-Net, Kling-Net | |||||||
DMX Channels | 8CH/12CH/73CH/132CH | |||||||
RDM | RDM ready for fixture remote monitor and settings | |||||||
Display | Blue TFT touch display | |||||||
Firmware Upgrade | Yes, via RJ45 Cable only | |||||||
