Product Overview
Description
Small home elevator lift for sale
Product Description
1.vertical elevating system. This durable and easy-to-use vertical lift is suitable for indoor or outdoor applications requiring vertical transportation up to 6 meters.
2.It can be directly installed into the ground without architectural supporting pits and easy to operate.
3.Its hydraulic or screw system offers passengers smooth and comfortable transportation and
different safety devices remove every hiding risk.
4.Emergency Descending:When there is no power or malfunctions, manually descend the device
5.It’s suitable for large-sized newly-built residential estates and those areas where there is compact land resource and etc.
Parameters
Platform size | 1300mm(L)* 900mm(W) or customized | |
Max Platform Height | 6000mm | |
Min Platform height | 80mm | |
Speed | 60mm/s | |
Load capacity | 250KG~350KG | |
Control voltage | 24V/DC | |
Power Output | 2.2KW | |
Power Input | 220V/50HZ/25A (or customized for local power supply) | |
Drive System | Hydraulic or screw | |
Control Mode | Inching Switch or Automatic | |
Drive Control | Self-resetting system | |
Overload | Protection Over current relay | |
Material of Platform | Checkered slip-proof aluminum alloy | |
Painting | Plastic electrostatic spraying | |
Guard panel & drive cabinet (framework) | Aluminum Alloy / 304 stainless steel
| |
Operation Panel | Polished aluminum Alloy | |
Working Condition | Both indoors and outdoors | |
Working temperature | From -50°~60°C | |
Installation
| Non-pit installation, directly fixed to concrete floor (the concrete floor below the platform shall not be lower than the ground) | |
Emergency Stop
| The lifting and lowering process can be stopped immediately by pressing the emergency button. | |
Safety device | Safety Interlock | Lock the platform when it is out of control |
| Safety Sensor | The operation must be stopped immediately the safety edge meets obstacles during operation. |
| Emergency lowering | The platform can be lowered by opening hydraulic valve manually or rolling screw rod. |
| Auto-flap | Turn up after lifting |
We need your information belows:
1.Loading capacity?
2.Lifting height?
Exhibition photos
FAQ
1. Are you a trader or manufacturer?
We are experienced, licensed manufacturer for over 15 years. We may offer low price and more direct service.
2. Warranty?
Main structure and machinery warranty for 12 months after delivery port.
3. How to deliver?
Based on the destination, it can transport by ship, by truck, or by railway, etc. By ship, our product is designed to fit in 40’HQ container or 20’ GP container, which saves shipping cost.
4. Do you accept OEM or ODM?
Yes.
5. How do we do installation? Can you send technician for assistance?
Operation manual and foundation drawing will teach you step-by-step. You may employ local engineering team or use your own team. Also, we can arrange technician to instruct installation, and to train your workers how to maintain. But the cost will be bear by buyer, including round-up air ticket, food, visa, accommodation, extra salary after agreed working days, etc.
6. Do we need to purchase extra easy wear parts?
We strongly recommend you purchase some along with the equipment, which saves time and transportation cost, when years later you need to change some easy wear parts, your project wouldn’t be delayed.
7. If we want to be your agent?
Agent, distributor, dealer, and sole agent, is highly wanted. We need local people to develop market for us, especially those with experienced after-sales service team. We will offer competitive agent price, market promotion support, technical support, and staff training. The number of agent is limited in certain area, so as to protect your interest.
