Electric stainless steel grater machine for cassava gari
Industry type cassava grater:


small cheap cassava grater:



Electric stainless steel grater machine for cassava gari
Processing Capacity: 3-6Tons/hour
Application Scope: Grating the cassava into slurry
Product Introduction: Cassava grater machine, cassava grating machine, cassava grinder, cassava grinding machine for cassava flour and garri processing
Product Description of Cassava grater machine
Cassava grater machine adopts two level pulverizing, the first level is rasp-type pulverizing, and the second level is hammer-type pulverizing, the combination of two levels sufficiently makes up their individual defects. It can be used for grating raw materials such as cassava, potato, sweet potato, yam etc. The efficiency can be improved by 45%-90% comparing to universal hammer mill.
Product Features of Cassava grater machine
1. The pulverizing cavity looks like a dropping cave, which can prevent the circumfluence of the raw material.
2. The hidden rotors can pulverize the materials completely.
3. Two level pulverizing: rasp-type and hammer-type pulverizing with super efficiency.
4. The distance between sifter and sinker is adjustable, which can make rough pulverizing, fine pulverizing and micro pulverizing are available in one machine.
5. Easy-open door makes maintains convenient.
6. Sieve will be bounded up after pressing. This enables the replacement much easier, and can close much tighter.
Technical Parameters of Electric stainless steel grater machine for cassava gari
Model No. | GD-G-660 | GD-G-900 |
Machine Material | Stainless Steel | Stainless steel |
Capacity | 3Tons/Hour | 6Tons/Hour |
Voltage | 380V & 50/60Hz 3Phase | 380V & 50/60Hz 3Phase |
Power | 11KW | 15KW |
Weight | 350KG | 450KG |
Dimension(L ×W ×H) | 1300×1000×1400mm | 1300×1300×1400mm |
our customers is checking our cassava grater machine :


Nanyang Goodway Machinery & Equipment Co., Ltd. is a leading manufacturer and supplier of Cassava & Potato Processing Machineries, focus on providing the system solutions in the fields of Cassava Starch, Potato Starch, Sweet Potato Starch, Cassava and Yam Flour, Garri/Gari, Fufu Flour, Cassava Chips processing since 1991 in the worldwide. Presently, most of our managers are technical and marketing experts, including more than 100 mechanical engineers, they are major in mechanical equipment and many years experienced in mechanical equipment manufacturing, research and development. So far Goodway has acquired 35 national patents in the field of cassava & potato processing machinery. Meanwhile, we cooperate with many high technology partners and Institutes, as well as many professional Universities all the time. In order to provide high quality products and services, Goodway adopts the advanced mechanical production line and internal management system, with the international standards as development objectives, pass the ISO9001:2015 certificate of quality system, ensuring all products delivered are 100% qualified. Materials and finished goods are inspected in strict compliance with standards. Goodway carries out a multiple stage quality management system: Incoming Quality Control(IQC), In-process Quality Control(IPQC), and Outgoing Quality Control(OQC). After-sales technical support and service for our customers. So far, the products of Goodway have been sold to more than 50 countries and areas, including Africa, South America, Middle Asia, East Europe and Southeast Asia, etc. And the growing trend still keeps at high speed with our better R&D, quality and service, we will try our best to supply better and better mechanical equipment solutions to satisfy our customers all over the world.
