|RIPPLE & NOISE(max.)||100mVp-p|
|SETUP,RISE TIME||500ms,20ms,50ms/230VAC 500ms,20ms,15ms/115VAC at full load|
|AC input current||0.7A/100VAC|
|AC inrush current||45A/230VAC|
|PROTECTION||OVER LOAD||110%~150%rated output power |
|Protection mode : Hiccup mode ,auto-recovery after fault condition is removed.|
|OVER VOLTAGE||105~135% rated output power|
|Protection mode :Clamp by zener diode,output short|
|ENVIRONMENT||WORKING TEMP.||-0℃ ~ +50℃ |
|WORKING HUMIDITY||20%~90% RH non-considering|
|STORAGE TEMP.,HUMIDITY||-20℃ ~ +85℃ 10~95% RH|
|TEMP. COEFFICIENT||±0.03% /℃(0~50℃)|
|Vibration||10~500Hz, 2G 10min./1 cycle ,period for 60 min. each along X Y Z axes|
|SAFTY & EMC||Withstand voltage||I/P-O/P:3000 VDC|
|Insulation resistance||I/P-O/P:100M Ohms/500VDC/25℃/70%RH|
|EMI conduction&radiation||Compliance to EN55024, EN61000-3-3|
|EMS immunity||Compliance to EN61000-3-3|
1. All parameters are specified at 230VAC input, rated load, 27℃ 70%RH ambient.
2. Ripple and noise are measured at 20MHz by using a 12 inch Twisted pair terminated with 0.1u and 47u capacitor.
3. Tolerance: includes set up tolerance, line regulation, load regulation.
4. DC voltage : the output voltage set at point measure by plug terminal &50% load.
5.Line regulation is measured from low line to high line at rated load.
6.Load regulation is measured from 20% to 100% rated load.
7.The power supply is considered a component which will be installed into a final equipment .The final equipment must be re-confirmed that it stills meets EMC directives.
Many power models-
5 Watts - 1800 Watts
Many voltage output-
5V, 7.5V, 9V, 12V, 13.8V, 15V, 18V, 24V,29V, 36V, 48V,50V,60V (Depend on your requirement).
We have professional engineer to make new design as your speical requirment.
We have the best professional and experienced engineer and the strict QC system.
The delivery time is 1-25 days which depend on quantity and details items.
T/T, L/C, Paypal, Western Union, Money Gram.
With more than 10 years experience,we can provide professional design solution for power supply according your requirement.
You are welcome to be our distributor or agent in all over the world for switch power supply.Please contact us for more details.
High quality adaptor ac to dc 12v lignther car 1.5a 18w great wall electronic with 55mm 25mm dc plug
