Pure sine wave home inverter 600W/800W/900W /1000W inverter

Product Overview

Description

Pure sine wave home inverter 600W/800W/900W /1000W inverter



Main features:

 Accurate pure sine wave output ;strong capacity of different load.
 Smart RS232 communication port .
 Advanced performance due to the CPU control.
 Wide range of power input and accurate output AVR.
 Perfect protection for overload ,short circuit ,over-voltage ,low-voltage and over-heating etc.
 LED/LCD display (optional).
 Adapt to various of power net well ,compatible with generator.
 UPS start automatically when the main power recover(optional).
 Intelligent battery management.

 Technology Specifitions:

MODEL	EW2150 1KM/S	EW2150 2KM/S	EW2150 3KM/S	EW2150 5KS	EW2150 6KS
CAPACITY	1KVA /600W	2KVA /1200W	3KVA /1800W	5KVA /3000W	6KVA /600W
INPUT
Voltage	100/110/120/127/220/230(± 25%) VAC
Voltage Range	81-145 VAC / 162-290 VAC
Frequency Range	60/50 ± 10% Hz (auto sensing)
OUTPUT
AC Voltage Regulation	±10%
Frequency Range	60 Hz or 50 Hz ±1 Hz
Transfer Time	Typical 2-6 ms, 10ms max.
Waveform (Batt. Mode)	Sine Wave
BATTERY
Battery Type & Number	12 V/7 AH x 2	12 V/12 AH x 2	12 V/12 AH x 4	12 V/17 AH x 4	12 V/17 AH x 4
Recharge Current	Long back up model:max 15A       Standard model:max 3A
INDICATORS
LCD/LED	Optional
PROTECTION
Overload	shut dowm if overload exceeds 120% /normal value for 30 seconds
Short circuit	Cut off immediately or input circuit breaker protection
ALARM
Battery back-up	Sounding every 4 seconds
Low Battery	Sounding every second
Overload	Audible alarm
Fault	Continuously sounding
PHYSICAL
M Dimension, D X W X H (mm)	375 x 130 x 190	452 x 192 x 338
M Net Weight (kgs)	12.0	23.0	27.6	33.7	33.7
S Dimension, D X W X H (mm)	375 x 130 x 190	452 x 192 x 338
S Net Weight (kgs)	9.6	17.0	23.7	33.7	37.3
OPERATING ENVIRONMENT
Humidity	0-90 % RH @ 0- 40°C (non-condensing)
Noise Level	Less than 45dB
Optional USB/RS-232 Port	Supports Windows® 98/2000/2003/XP/Vista/2008, Windows® 7, Linux, and MAC
