Dry full-automatic laser particle size analyzer capable of controlling feeding by computer

Description:

Full-automatic test is the first one-key automatic test in China. All operating instruments are automatically completed without customer assistance. It is the first real dry full-automatic test instrument.The operation mode software controls the operation automatically.
Automatic Calibration of Light Path Alignment
96-channel simultaneous acquisition mainboards are currently exclusively used in China for 96-channel simultaneous acquisition mainboards, which have more accurate data and higher stability.
The traditional vibration feeding of the latest active feeding system is no longer suitable for the feeding of some new drugs. The newly improved active feeding system perfectly tests all powdered samples and feeds evenly.
The software function analysis mode includes free distribution, R-R distribution, lognormal distribution, classification statistical mode according to objective, etc. it meets the different requirements of different industries on the statistical mode of measured sample particle size.
Statistical methods: volume distribution and quantity distribution to meet different statistical methods for particle size distribution in different industries
Statistical comparison can be used for statistical comparison and analysis of multiple test results, which can obviously compare the differences of test results of different batches of samples, samples before and after processing and at different times, and has strong practical significance for quality control of industrial raw materials
Self-DIY display template users customize the data to be displayed, and calculate the percentage according to the particle size, the particle size according to the percentage or the percentage according to the particle size interval, so as to meet the characterization methods of particle size testing in different industries. Diameter distance, consistency, interval accumulation, etc
Test Report The test report can export various forms of documents such as Word, Excel, picture (Bmp) and Text to meet the requirements of viewing the test report and quoting the test results in scientific research articles in any situation.
Multilingual support Chinese and English language interface support, can also be embedded into other language interfaces according to user requirements.
The intelligent operation mode is truly fully automatic and no one intervenes, and no one is interfered by factors. You only need to add the sample to be tested according to the prompt, and the repeatability of the test results is better.
Specifications
nkt2010-l
Implementing
ISO 13320-1: 1999; GB/T19077.1-2008
test range
0.1μm -800μm
Number of detector channels
76
Accuracy error
< 1% (D50 value of national standard sample)
Repeatability error
< 1% (D50 value of national standard sample)
The oil-free mute air compressor
has a dust filtering function to ensure the accuracy of the test.
Cold dryer
The freeze dryer can filter the moisture in the air to ensure the dispersion effect
The misoperation protection
instrument has misoperation self-protection function, and the instrument does not respond to misoperation.
Laser parameters
import fiber output high-power laser λ = 650 nm, p > 15mw (constant power, automatically adjustable)
Dispersion method
High pressure air dispersion
Test speed
< 1 min/time (excluding sample dispersion time)
Volume
980 mm * 410 mm * 450 mm
Weight
35Kg
Company Profile
Recommend Products
Certifications
Packing&Shipping
FAQ
Purchase laser particle size analyzer need know points:
1) What materials need test?
If suspension/emulsion, must choose liquid dispersion particle size analyzer, and some materials are also reacted with water, so
need liquid dispersion particle size analyzer also.
Generally, cement, metal powders and pharamcy materials need dry dispersion model particle size analzyer.
2) What size range need test?
By now, Based on MIE scattering, laser particle size analyzer can test the particle range is 0.01um-2000um.
If materials range is not so wide, for example, 10um-20um, smaller range of particle size distributon choose closer range model
will be preciser, no need to buy large range model.
3) What is dispersion media?
For liquid model, in order that sample can disperse well and circualte in the laser particle size analyzer, generally we need use
water, alochol or organic solvent as dispersion media.
For dry dispersion model, just use compressed air as dispersion media.
In the current market, Dry laser particle size analyzer cost is higher than liquid dispersion models, so if can test well, liquid
model is better.
More questions, please contact us, we will offer you the best suitable laser particle size analyzer for you!
