| Machine Color | According to customers' requirement |
| Motor | Siemens/Made in China |
| Inverter | Delta/Made in China |
| Switch | Schneider/Made in China |
| Product Keywords | self close plastic bag making machine |
Characteristics:
1. Whole machine controlled by central PLC control system with man-machine More stable performance, easy for operation and maintenance.Chinese and English interface language can be shifted easily
2. Constant auto-tension control for unwinding, LPC edge alignment, AC inverter constant speed auto material feeding.
3. Imported auto-tension control for unwinding, LPC edge alignment,AC inverter constant speed auto material feeding
4. Main motor for up-down sealing and pressing equipped control system
5. PID for sealing bar temperature adjustment, no touch auto control, centralized setting in man-machine Interface
6. Equipped with Pneumatic multi-function auto punching device, trim cutting and auto rewinding and static eliminator
7. Temperature adjustment range: 0-300`C
8. Counter: quantity, batch accumulation, pre-set available
9. Operation method: by length fixation control and/or by photocell tracking control.
10. Punching deviceiworking rhythm can pre-set as continuous, interval or stop, punching time can be pre-set.
11. Material Skip Feeding: one to six times available
12. Batch Conveying Function available, the quantity of batch can be preset
Main Parameter:
type | JM-ZUB500 | JM-ZUB600 |
Max.diameter of roll material | 600MM | 600MM |
Max width of roll material | 850MM | 1050MM |
Max capacity | 150time/min | 160time/min |
Max,machine speed | 35M/MIN | 40M/MIN |
Total power | 40KW | 50KW |
Weight of machine | 5000KG | 5500KG |
Overall dimension | 10500X1650X1870MM | 10500X1850X1870MM |
