Used flexo printing machine two colour flexographic color

Share on (62389301187):


Price:

Quantity:


Product Overview

Description


Product Description

Used flexo printing machine two colour flexographic color

used flexo printing machineused flexo printing machineused flexo printing machineused flexo printing machineused flexo printing machine

Product Detail

Machine ColorAccording to customers' requirement
MotorSiemens/Made in China
InverterDelta/Made in China
SwitchSchneider/Made in China
Product Keywordsused flexo printing machine

Characteristics:

This flexible printing machine is suitable for printing such packing materials as polyethylene, polypropylene plastic bag, cellophane and roll paper, etc. And it is a kind of ideal flexo printing equipment for producing paper packing bag for food, supermarket carry bag, vest bag and clothes bag, etc.

1. Easy operation, flexible starting, accurate color register.

2. The meter counter can set printing quantity according to the requirements Stop the machine automatically at the set quantity or when the material is cut off.

3. Lift and lower the printing plate cylinder manually, it will automatically stir the printing ink after lifting.

4. The printing ink is spread by the knurled cylinder with even ink color.

5. Reliable drying system coordinated with high-speed rotation, it will automatically break circuit when the machine stops.

6. 360 continuous and adjustable register device.

7. The imported frequency control of motor speed adapts to different printing speeds.

8. There are Inching/Stopping buttons on the plate roller base and material rolling rack so as to make it easy operate the machine when the plate is installed.

Main Technical Variables:

Model

YT-2600

YT-2800

YT-21000

Max. width of printing material

600mm

800mm

1000mm

Max. printing width

560mm

760mm

960mm

Length range of printed product

191-914mm

191-914mm

191-914mm

Max. diameter of roll material

450mm

450mm

450mm

Printing speed

5~50m/min

5~50m/min

5~50m/min

Thickness of plate (Including two-sided glue paper)

2.38mm

2.38mm

2.38mm

Total power

8kw

10kw

12kw

Weight of machine

1800kg

2000kg

2200kg

Overall dimensions(L*W*H)

2300*1860*2145mm

2300*2060*2145mm

2300*2260*2145mm

Model

YT-21200

YT-21400

YT-21600

Max. width of printing material

1200mm

1400mm

1600mm

Max. printing width

1160mm

1360mm

1560mm

Length range of printed product

191-914mm

191-914mm

191-914mm

Max. diameter of roll material

1000mm

1000mm

1000mm

Printing speed

5~50m/min

5~50m/min

5~50m/min

Thickness of plate (Including two-sided glue paper)

2.38mm

2.38mm

2.38mm

Total power

13.5kw

15.6kw

17.3kw

Weight of machine

2400kg

2600kg

2800kg


Company Information
used flexo printing machine

OUR FACTORY

Wenzhou Jiamao Machinery Company locates in economic vibrant Ruian City on the southeast coast of Zhejiang Province.

It is a professional manufacturer of soft packaging machinery, such as roto printing machine, flexo printing machine, lamination machine, film blowing machine, bag making machine and recycling machine, etc.

MAIN
MARKETS

With long producing experlence, good quality and perfect after-sell service, we get consistent praise and gain great market. Our products are exported to Southeast Asia, the Middle East, Africa, Russia, America and Europe. Now we are expanding the market in South America.

Certifications

OUR CERTIFICATES

used flexo printing machine
Exhibition

used flexo printing machine

FAQ

FAQs

—— 01 ——

Are you a factory or trading company?

We are an actual factory and manufacturer in the line of printing and packing machine for 20 years.

—— 02 ——

Where is your factory loaded?

Located in Rui’an city, Zhejiang Province. By plane around 1.5h from Shanghai to WENZHOU AIRPORT. By high speed train around 4 hours from Shanghai to RUIAN STATION.

—— 03 ——

Which industries are widely used in of your machine?

Food packaging, industry and agriculture, etc.

—— 04 ——

How about the payment term?

Our payment term is 30% T/T in advance before production, the balance 70% should be paid before delivery. 100% irrevocable L/C at sight is acceptable.

—— 05 ——

What about your main market?

Our products be sold well in 30 provinces in China, also we pay attention to developing the oversea market, such as Europe, Russia, Southeast Asia, Middle and South America, Africa, and other countries.

—— 06 ——

How does your factory do regarding quality control?

GREAT WALL always attaches great impartance to quality controlling from the every beginning to the every end. We have passed SGS and CE certifications.

—— 07 ——

What about the after sales service?

We offer comprehensive maintenance options to prevent equipment issues before they become problems. Also we offer one year guarantee period.




—— 08 ——

What about the installation services?

We will provide the technical for your operation smooth transition and support for installing, debugging, operation of the machine, it will indicate you how to use this machine well.

—— 09 ——

What are your products advantages?

1. Top quality 2. Large output 3.Delivery timely 4. Competitive price     5.Satisfying service  6. Old and experienced factory

—— 10 ——

Can we order on alibaba.com?

Of course! We will give you more discount if you order on alibaba.com.
