Product Item:KOK POWER Rechargeable Deep Cycle 18650 NMC 36V 20Ah battery pack for electric bike
1. Scope
This document describes the Product Specification of the Lithium iron phosphate battery supplied by KOK (KOKPower Limited ).
2. Model: KOK-XC1812-3620
Specification
No.
Items
Specifications
1
Nominal Voltage
37V
2
NominalCapacity
20Ah
3
Cell inside
XC18650 3.7V 2600mAh
4
Configuration
10S8P
5
Standard Charge Current
4A (0.2C)
6
Max. Charge Current
20A (1C)
7
Protected Circuit Board(BMS)
BMS-Li10S3010-591
8
Continue Discharge Current
30A
9
Peak Discharge Current
60A
10
Full Charged Voltage
42V(4.2V per cell)
11
Charge Cut-off Voltage
42.5V (4.25V per cell)
12
Discharge Cut-off Voltage
25V (2.5V per cell)
13
Battery Net Weight
4.16Kg
14
BatteryDimension
212*138*78mm
15
Connector
Input: a pair of wires(17.5cm)
Output: a pair of wires(24cm)
16
Operating Temperature
Charging:0°C ~ 45°C
Discharging: -20°C ~ 55°C
17
Storage Temperature
(Recommended to store 20 ± 5°C for long term storage)
18
Life Cycle
>800 times (80% of initial capacity at 0.2C rate, IEC Standard)
Application
1) Electric vehicles and charging stations, tourist coaches, yachts, wind and solar energy storage power, traffic signals
2) Solar hybrid street lighting, UPS power supply, home storage
3) Coal, disaster relief emergency, weather radar, electricity, smart grid, communication base stations
4) Hospitals, finance, telecommunications , system critical backup power systems
Pakage: OEM gift box. We can baranding OEM design for you
Come and get one. Email us, call us at 0086-755-2937 1122; or you can send us message below, we will reply you in time.
Company Information
KOK POWER LIMITED (KOK), founded in 2011, is pioneer of smart lithium-ion battery systems in China. Our smart batteries can display & monitor the batteries status and thus enable the devices to conserve and use power intelligently with a patented built-in battery management system (BMS) via blue-tooth or other communications through APP or on screen.
KOK is strong in R&D and manufacturing of smart battery systems, widely used in fields such as E-mobility (e-bike, e-scooter, e-skateboard, e-motorcycle, e-tricycle/rickshaw, e-wheelchair, e-golf cart, e-forklift, e-tourist vehicle, RV/caravan,marine,etc.), Energy Storage Systems (solar/wind system, telecom/base station, uninterruptible power supply/UPS/backup system) and engine starter batteries. KOK batteries can readily replace the outdated, bulky and pollutant Lead-Acid / AGM/ GEL/SLA batteries with the latest smart lithium battery technology.
Following are our company production manufacturing
KOK staff, from senior management to direct operators, have over 8 years’ experience of building batteries for many applications.All assembling operators are trained to high standards;and our sales team are good communicators. We will work with you to find a custom power solution for your applications and will provide you with complete design, build and test solutions tailored to your specific needs.
KOK has been awarded as Hi-Tech Company of Guangdong Province, and products are designed to be safe, reliable and competitively priced. All our products are designed and manufactured to the highest standards and meet or exceed industry safety and environmental standards including: ISO9001, IEC62133, UL1642 / UL2054,CE,RoHS.
