low cost engine lathe machine/mini engine lathe/Horizontal engine lathe
- Category: >>>
- Supplier: Shandong Sanzheng Machine Tool Co. Ltd.
Share on (62393273402):
Product Overview
Description
Product Description
low cost engine lathe machine/mini engine lathe/Horizontal engine lathe
For CW6163B lathe, its bed is of a structure combining oblique stiffener of large width to enhance its
rigidity as a whole and operate in concentrative way, the slide carriage is provided with quick feed and
the spindle's normal or reverse rotation and braking is controlled hydraulically. The bottom slide surface
of the guide rails is of the TSF wear-resistant embedded structure to move freely and smoothly, long
service life. The outside-of-stock lubrication system is used to increase its processing accuracy.
rigidity as a whole and operate in concentrative way, the slide carriage is provided with quick feed and
the spindle's normal or reverse rotation and braking is controlled hydraulically. The bottom slide surface
of the guide rails is of the TSF wear-resistant embedded structure to move freely and smoothly, long
service life. The outside-of-stock lubrication system is used to increase its processing accuracy.
Description of product
The spindle bore is 105 mm and the tail stock is equipped with a graduation disc and graduation lines, more visually usable. The machine is nice in appearance and easy to clean and maintain.
Advantages of product
The lathe can be used
in various milling and turning, for instance, milling inner/outer cylindrical/conical surfaces, formir
swiveling surface and annular groove, and it may also be used to drill/ream bores, tap and knurl etc.
in various milling and turning, for instance, milling inner/outer cylindrical/conical surfaces, formir
swiveling surface and annular groove, and it may also be used to drill/ream bores, tap and knurl etc.
Size Information
low cost engine lathe machine/mini engine lathe/Horizontal engine lathe
Model | CW6180B |
Max swing over bed | 800mm |
Guideway width | 550mm |
Max workpiece length | 5000mm |
Max swing over carriage | 550mm |
Hole through spindle | 105mm |
Number of spindle speed changes | 18 steps |
Spindle Speed Ranges | 17-1000r/min |
Voltage | 220/380V |
Main motor power | 11KW |
Related Products
Packing&Shipping
Company Introduction
low cost engine lathe machine/mini engine lathe/Horizontal engine lathe
Shandong SanZheng Machine Tool CO., LTD., a large-scale professional lathe manufacturer, is a modern enterprise which covers the area of design, research, production, and sale and after-sale service. It has more than 20 years experience in manufacturing conventional lathe, pipe threading lathe and CNC lathe. ShanZheng is an enterprise which owns technology casting, forging, machining, assembly, heat treatment. The CAD and ERP are widely used in the Enterprise informatization management and the development of the new product.
Shandong ShanZheng Machine Tool CO., LTD. has passed the ISO9001 quality management system certification, CE certification and obtained the right of import and export. It has been rated as the “top enterprise ", "trustworthiness enterprise", "advanced enterprises for independent innovation" by the China machine tool industry for many years.
Shandong ShanZheng Machine Tool CO., LTD. has passed the ISO9001 quality management system certification, CE certification and obtained the right of import and export. It has been rated as the “top enterprise ", "trustworthiness enterprise", "advanced enterprises for independent innovation" by the China machine tool industry for many years.
The products are not just sold in China but also exported to Germany, Australia, Saudi Arabia, Holland,Chile,Singapore and other countries. We are the largest production suppliers of pipe threading lathe in Germany. High-quality product and timely after-sales service help us won the unanimous trust and favorable comment from both the domestic and foreign customers!
