Portable 200kg/400kg 220V Wire Rope Mini Electric Hoist Crane

Product Overview

Description













                                                                           Product parameters

Model	Method of Use	Rated Voltage(v)	Input Power(w)	Capacity(kg)	Lifting speed(m/min)	Qty/Carton(pc)	Package size(cm)	N.W/G.W(kg)
PA200	Single hook	220/230	510	100	12/6	2	47*37*16	22/24
	Double hook			200
PA250	Single hook	220/230	580	125	12/6	2	47*37*16	23/25
	Double hook			250
PA300	Single hook	220/230	650	150	12/6	2	47*37*16	24/26
	Double hook			300
PA400	Single hook	220/230	850	200	12/6	2	52*45*17.5	33/35
	Double hook			400
PA500	Single hook	220/230	950	250	12/6	2	52*45*17.5	34/36
	Double hook			500
PA600	Single hook	220/230	1150	300	12/6	2	52*45*17.5	33/35
	Double hook			600

                          Product Material

No.	Name of the part	Material
1	Cover	A4 steel
2	stator	silicon steel
3	gear box	20Cr
4	Bear	45# steel
5	bear shaft	58#-62# steel
6	Motor cover	aluminum
7	Brake	Iron Powder
8	Plastic parts	engineering polypropylene
9	Capacitance	Polypropylene film









                       Packages & shipping
