* Support 8*XPOE+8* IPC video input; * Support H.265+ Decoding; * VGA、HDMI simultaneous video output; * Mini 1U Case, 1SATA(Up to 8TB); * 1*10/100Mbps auto-sensing Ethernet port, RJ45 port； * XPOE network port power supply * Support the Onvif protocol; * Support GB28181 (Optional); * Support remote access, support ARSP; * "Support DHCP, FTP, DNS, DDNS, NTP, UPNP, EMAIL, * 3G, WIFI, IP search, Alarm center, etc ;" * Mobile phone remote monitoring (iOS, Android); * Multi browser access (IE, Chrome, Firefox, Safari); * Support for more than twenty languages; * Perfect protection circuit, unique triple watchdog function; * Support WEB, CMS, VMS, MYEYE Platform;
Model
NVR8908T-8PXC
System
processor
HI3520DV400
system
Embedded Linux
Video
Video input
8*1080P（XPOE）；
8*1080P(XPOE)+8*1080P(IPC)
Playback
8*1080P；4*1080P
Decode
H.265+
Audio
Compression
G.711a
Intercom
Unsupport
Management
Record mode
Manual>Alarm>Motiondetection>Timing
Inquire mode
Inquire by Time/Calendar/Event/Channel
Storage mode
HDD Storage, Network Storage
Backup
Network, USB, SATA
Interface
XPOE ports
8*XPOE
HDMI output
1*HDMI (MAX:1080P)
VGA output
1*VGA (MAX:1080P)
Audio I/O
0/0
Alarm I/O
0/0
USB Port
2*USB2.0 ports
HDD
1*SATA interface (Up to 8TB)
General
Temperature
0 ℃ - + 55 ℃
Humidity
10% -90% RH
Power supply
12V/6A
Consumption
<10W(Without HDD)
Weight
Around 1.2KG
Dimension
255(L)* 236mm(W)* 44mm(H)
Related Products
Our Company
Hangzhou Xiongmai Technology Co., Ltd., an innovative technology company specializes in audio&video hardware research and development established in 2008, is a global leading provider of safe&security solutions and technologies. We are committed to providing the productions solutions and technology service in audio &video areas, continuously boosting our customer experience, and creating maximum value for them. Now, as our products and solutions have been applied to more than 80 countries, we have been the provider of the majority of the security manufacturers.
Certifications
Packing & Delivery
FAQ
Q:1.How to provide you a good market suggestion? A: We provide you an accurate and comprehensive marketing suggestion in accordance with alibaba periodical big data, google big data, our company data, in combination with our experience.
Q: 2. How to order?
A: Please contact us online or send us email, we will send you PI, once receiving your payment, we will send out goods soon and tell you the tracking number. Or we could communicate to start an order on line by trade assurance.
Q: 3. How to proceed LOGO print order? A: 1) send us the logo files, once receiving your payment(large order 30%), we will arrange to design the logo; 2) after received your confirmation of the logo, we will do sample and send it you check; 3) if you confirm the sample is ok, we will produce the mass; 4) once ready, please pay the rest payment and we will send out goods and tell you the tracking number
Q: 4. Can I do my original design products? A: Yes, our engineer team will always be ready for your any needs.
Q: 5. What is the guarantee of our products and how about the returns? A: 1) 12 months warranty, low-value consumption goods is not within the scope of the warranty; 2) Warranty service will be honored if the damage is not caused by human; 3) Please send back the defective goods within the warranty period, we will repair them or send you new free; 4) If there are only several pieces accessory(the fee is less or around shipping fee) are damaged, please send us some pictures and videos about the detail problem. Once confirmed the problem, we will send you free new goods together with your next order.
