6 Six Color High Speed 130m/min Double Sides Printing Plastic Nylon Polythene PE BOPP CPP Film Paper Roll Flexo Printing Machine

Description:

Flexographic printing machine, also called aniline press which uses photosensitive resin plate as the printing plate of printing machine. It adopts environmental ink and has advantage of low edition-producing cost, this is an ideal machine for small mass lots, large variety production manufacturer. This machine is suitable for printing such packing materials as HDPE, LDPE polyethylene, polypropylene plastic bag, glass paper and roll paper, etc. And it is a kind of ideal printing equipment for producing paper packing bag for food, supermarket handbag, vest bag and clothes bag, etc.

Main Features:
1. Applied to the printing of plastic film, PE, PP, BOPP, OPP, hdpe, ldpe, paper and so on.
2. Adopt synchronous belt drive, less running noise, higher stability.
3. Adopt the Denmark chamber doctor blade system, so that the speed of the whole machine can reach 150m/min;
4. The LPI can be decided according to the needs of customers by using the top quality brand ceramic anilox rollers.
5. With the printing imaging inspection equipment;
6. Low speed and full load startup; stable running by tension control when increasing and decreasing speed, noise is decreased
7. High dots presentation rate under high speed; clear and vivid stratification of screen printing; strong stereo effect and
accurate registering.
8. The special made modulus angular gears adopted; accurate printing size and full printing specifications (5mm is a spec)
9. With the air exhaust, blowing and heating settings; the heating system adopts the central thermostatic control system and
group management, also with the cold air forming devices.
10. Printing rolls should keep moving while machine halted
11. Automatic material roll unwinding with cylinders, and auto magnetic tension, edge correction system.
12. Rewinding unit adopts speed mode with tension arms, frequency motor, floating roll, and PLC control.
13. Printing plate lifting system with hydraulic pressure control.
14. Reversible printing available.

Optional:
1. Additional printing rollers for different printing length
2. Plate mounting machine
3. Plate making machine
4. Printing roller cleaning machine
5. Crane unloading materials rolls
