50mm precision vertical drilling machine Z5150B for metal
- Category: >>>
- Supplier: Tengzhou Chenghai Machine Tool Co. Ltd.
Share on (62398552918):
Product Overview
Description
50mm precision vertical drilling machine Z5150B for metal
We are manufacturer of vertical machining center, cnc milling machine, cnc lathe, radial drilling machine , milling machine,machine, lathe and shaper. We have our own factory, so we can provide the factory price with good quality.
We always pay more attention to the quality of our machines under the ISO standard system, and our quality
control team are responsible to insure the product quality in every process. So you can trust us. Customers'
satisfaction is the eternal pursuit of our company.
Chenghai machine to ensure product quality, implementation of stringent vendor management, all of the key
components of the machine purchased directly from the country of origin, shorten delivery time, reduce production
costs and improve product quality.
Product Description
Specifications of 50mm precision vertical drilling machine Z5150B for metal:
Specification/Model | Z5150B | Z5150B-1 |
Max drilling diameter | 50 mm | 50mm |
Spindle taper | MT5 | MT5 |
Spindle travel | 250mm | 250mm |
Spindle box travel (manual) | 200mm | 200mm |
Spindle speed step | 12 | 12 |
Spindle speed range | 31.5-1400 rpm | 31.5-1400 rpm |
Spindle speed step | 9 | 9 |
Spindle feed range | 0.056-1.8 mm/r | 0.056-1.8 mm/r |
Table size | 560×480mm | 800×320mm |
Longitudinal/cross travel |
| 450/300mm |
Vertical travel | 300mm | 300mm |
Max distance between spindle and table surface | 550mm | 750mm |
Main motor power | 3kw | 3kw |
Overall size | 1090×905×2465mm | 1300×1200×2465mm |
Weight | 1250kg | 1350 |
Our Services
1. Your inquiry and email will be replied within 24hours.
2. If you need to develop products with your own specification, we can help you to work it out.
3. Always be honest, never lie to customer, and never declare anything we don't have.
4. 3 First: Customer, Quality and Service!
FAQ
1. Payment Method:30% deposit T/T in advance, rest against the copy of B/L or before delivery.
2. Delivery Time:
For one set machine, will be within 15 days after deposit.
For 5-10 sets same machines, will be within 30 days after deposit.
For 5-10 sets different machine, will be more than one month.
3. MOQ:
1 set machine
4. Shipping: Usually by sea
