Factory Sell Centiz Panel Board Type Pleated Activated Carbon Air Conditioner Air Filter Pre Filter Prefilter 592x592x22mm

Product Overview

Description



592x592x22mm Centiz Primary Efficient Panel Board Type Pleated Activated Carbon Air Conditioner Air Filter Pre Filter Prefilter



Product features:



Small volume and density, large specific surface area, high adsorption efficiency, low drag coefficient, no odor

Its carbon content is around 35%-50%

Sealant: hot melt adhesive

Acid and alkali resistance, VOC(volatile organic compounds)

Applicable temperature: 0-40 °C

Applicable humidity: <70% relative humidity





Application of product:



Ventilation and air conditioning system with tight installation space and need to remove odorous gas pollutants

Commercial and civil buildings such as airports, high-end hotels, office buildings, and large shopping malls;

Air supply air-conditioning systems for museums, libraries, art galleries, etc.;

The best choice for optimizing the filtration function of current comfort air conditioning systems





Efficiency:  G4





Specification list:



Nominal size	Actual size	Pleated number	Filter material area	Activated carbon weight	Air volume	Pressure loss
(inch)	(mm)	(pleat)	(m2)	(Kg)	(m3/h)	(Pa)
(W×H×D)	(W×H×D)
24×24×12	592×592×46	33	1.9	0.76	3400	180
12×24×12	290×592×46	16	0.9	0.36	1700	180





1.Certificates:

RoHs,UL,SGS,MSDS,DIN53438



2.Payment terms:

50% deposit upon getting the order,balance against the B/L copy.



3.Delivery date:

About 7 working days(≤500pcs), special order is negotiable to be quicker.



4.Sample Terms:

We can supply 1-2 small samples for tree but express cost is covered by your side.



5.Minimum Order Quantity:

No strict principle for standard sizes,but 50pcs for non-standard dimensions or types.



6.Price Terms:

EX-WORKS, FOB, CNF, CIF OR DDU is available and up to you.



7.Lead time:

3 Days for a 40ft container, weeks for two 40ft container.



8.Factory:

Our factory located in Jiangsu, about 2000sqm, with 30 workers.
