1060 Aluminum Coil plate 3003 5052 5754 1100 2024 t651 aluminum coil plate complete wide alloy aluminum coil roll strip
- Category: Aluminum >>>
- Supplier: Tianjin Longford Metal Products Co. Ltd.
Share on (62403526355):
Product Overview
Description
1060 Aluminum Coil plate 3003 5052 5754 1100 2024 t651 aluminum coil plate complete wide alloy aluminum coil roll strip
| Content | Aluminum Coil,Aluminum Alloy Coil,Aluminum Coil Plate/Sheet |
| Thickness | 0.1mm-5.0mm |
| Width: | 100mm-1500mm |
| Surface | Silver,Polished Or Color Painted |
| Application | Commercial and Military Aircraft, Aircraft Structures and Components, General Sheet Metal Work, Machinery, Military Equipment, Vehicle Parts, Structural Applications, Rivets |
2000 Series Aluminum Coil Chemical Composition
ALUMINIUM CHEMICAL PROPERTIES | |||||||||||||
ALLOY NUMBER |
EURO. NAME | ASTM NAME |
TYPICAL CHEMICAL COMPOSITION % | ||||||||||
|
|
UNS |
Al |
Cr |
Cu |
Fe |
Mg |
Mn |
Si |
Ti |
V |
Z |
Others |
1000 SERIES (PURE) | |||||||||||||
1050 | AW-1050 | A91050 | Balance | - | 0.05 | 0.04 | 0.050 | 0.05 | 0.25 | 0.03 | 0.05 | 0.05 | - |
1100 | AW-1100 | A91100 | 99.00 | - | 0.05 - 0.20 | Si+Fe | - | 0.05 | 0.95 | - | - | 0.10 | 0.05 |
2000 SERIES (ALLOYED WITH COPPER) | |||||||||||||
2024 | AW-2024 | A92024 | Balance | 0.10 | 3.80 - 4.90 | 0.5 | 1.2 - 1.8 | 0.30 - 0.90 | 0.50 | 0.15 | - | 0.25 | 0.05 |
Military Aircraft Aluminum Alloy Coil Mechanical Property
ALUMINIUM MECHANICAL PROPERTIES | |||||||
ALLOY NUMBER |
EURO. NAME | ASTM NAME UNS | Proof Strength 0.2% Min (N/mm2) |
Tensile Strength | Elong. % Min. (50mm Gauge Length) |
Hardness Max (VPN) |
Tempers Available |
1000 SERIES (PURE) | |||||||
1050 | AW-1050 | A91050 | Mechanical Properties available on request | ||||
1050A | AW-1050A | A91050A | 20 min | 65-95 | 20 min | 20HBW | 0, H111, H112, H12, H14, H16, H18, H19, H22, H24, H26, H28 |
1070A | AW-1070A | A91070A | 15 min | 60-90 | 23 min | 18HBW | |
2000 SERIES (ALLOYED WITH COPPER) | |||||||
2024 | AW-2024 | A92024 | 140 max | 220 max | 12 min | 55HBW | 0, T4, T3, T351, T42, T8, T851, T62 |
2024 T651 Aluminum Alloy Coil Stock Range
2024 Aluminum Alloy Trim Coil Processing
2000 series metals are alloyed with Copper, providing good mechanical properties that can exceed those of Carbon Steel, but are less corrosion resistant than other alloys. 2000 series can be precipitation hardened to increase strength
Aluminum Copper Alloy Coil Application
Company Profile
FAQ
Aluminum Coil Anodizing&Finishing Options
• Standard – Matte,Satin,Natural clear anodizing,in addition to mill finishes
• 2 Step coil anodizing– Bronzes, Dark Bronze,Black
• Color dye coil anodizing
• Anodized coating thickness – up to 11 micro(0.425 mils) of anodic coating
• Coil Slitting • Coil Embossing
