Pure Water Reverse Osmosis System Plant / RO Treatment Plant

Pure Water Reverse Osmosis System Plant / RO Treatment Plant

Reverse Osmosis System Plant is an equipment to purify the saltine water with the action of pressure difference of semi permeable membrane. It is effective with asbestos, many taste, colour and odour producing chemicas, particulates, total dissolved solids, turbidity and radium. RO system is widely used in water supply treatment, purification for tap water, seawater and brackishwater, pure water and ultrapure drinking water production, power stations, electronic industries, and medical treatment. It is capable of removing 90-99% of total dissolved solids (TDS), 99% of organic, including pyrogens,and 99% of all bacteria in the feed water.
Raw water source:Bore whole, river, well, mountain spring, lake, etc
Raw water pump/multi pump:Nanfang, Grundfos
Filter media:Quartz sand filter, active carbon filter, security filter( PP filter)
RO Membrane:Filmtec Dow,Hydranautics

Working process
1. Raw water pump-- provide the pressure to quartz sand filter/active carbon filter.
2. Multi-medium filter-- get rid of turbidity, suspended matter, organic matter, colloid, ect.
3. Active Carbon filter--Remove the color, free chloride, organic matter, harmful matter, ect.
4. Softener--exchange "ions" of calcium and magnesium with the most common and easiest method.
5. Micron filter--prevent large particles, bacteria, viruses into RO membrane, accuracy is 5um,
6. High pressure pump-- Provide the high pressure to RO membrane ro.
7.RO system-- main part of the plant. The RO membrane's desalting rate can reach 99%, removing over 99% ions.

Raw Water Pump-Active Carbon Filter / Silica Sand Filter/ Precision Filter

RO System

Ozone Mixing Tower - Storage Water Tank

Pipe / Valves

Technical Dates

We aslo supply Water Bottling Plant
