4x4 HDMI/DVI/VGA/SDI Matrix Switcher Mixer up to 3840x2160P@30Hz Video Matrix

4x4 HDMI/DVI/VGA/SDI Matrix Switcher Mixer up to 3840x2160P@30Hz Video Matrix

(Note: The price listed here is for standard RS232 serial control. If need TCP/IP control, please contact us for more details.)

Brand Name:   LINK-MI

Model No.:       LM-MX44H

Product Type:  4K 4x4 Matrix Switcher System

    LINK-MI LM-MX44H 4K 4x4 Matrix Switcher is a high-performance video signal professional switching device for cross-switching of multiple video signal input and output. It adopts advanced high-performance image processing chip to minimize signal transmission attenuation, image and the sound signal can be high fidelity output.
    The Matrix is mainly used in broadcasting and television engineering, multimedia conference halls, large-screen display engineering, television teaching, command and control centers and other occasions. This product supports chassis keys, infrared remote control, RS-232 serial port, TCP/IP (non-standard) and open control code for central control.

1) Integrated structural design, standard 4 HDMI inputs and 4 HDMI outputs, compatible with HDMI, DVI signal format, support HDCP 1.4 version

2) Support the highest resolution: 3840x2160P@30Hz

3) Support EDID transparent transmission function, and also set fixed EDID identification information

4) Interface bandwidth 3.4Gbps (total bandwidth 10.2Gbps)

5) Support Blu-ray DVD or other devices that require HDCP decoding

6) With power-down memory function and power-off field protection function

7) Multiple control ways: standard chassis button, infrared remote control, RS-232 serial port, central control, optional TCP-IP control

8) Power supply: 100~240V AC, 50/60HZ
