DMG 1 ELITECH DOUBLE DIGITAL PRESSURE GAUGE
- Category: Refrigerator & Freezer Parts >>>
- Supplier: Jinan Retek Industries Inc
Share on (62407781176):
Product Overview
Description
Product Description
DMG-1 ELITECH DOUBLE DIGITAL PRESSURE GAUGE
This product is mainly used for air exhaust and compression in refrigeration and maintenance operation, refrigerant charging of air-conditioning systems. It can display pressure in real time.
Features:
High-quality dual-table valve with imported pressure sensor, high precision, excellent workmanship, stable performance; Large screen, display data clearly; High grade refrigerant pipes, reducing leaks; Battery-powered, low power consumption, long lifetime; Rubber jacket, beautiful and durable.
Parameters:
Pressure Measuring Range: -0.100~5.000 MPa
Operating Temperature and Humidity: -10~60℃; 35%~85%RH
Resolution pressure: 0.001MPa; temperature: 0.1℃
Accuracy pressure: ±0.5%FS (22℃~28℃); temperature: ±1℃
Battery Life: Six months
Power supply: 3V CR2450 button battery
Sampling Period: 1.2s
Battery Indicator displays "LOB" at low battery
Display 37mm x 17mm LCD/gren backlight
Measurement Units: MPa, kPa, bar, psi, kgf/cm2, mmHg
Out-of-Range Alarm pressure: FULL;temperature:--
Package:
Double core valve * 2;
1.5m fluorine hose * 3 (Min pressure: 800psi; max pressure: 4000psi)
High and low pressure test connector * 2 (Low side: blue; high side: red)
Corkscrew * 1
Dual purpose valve wrench * 1
R410A adapter * 1
Blow molding package
Manual * 1
