Настольный Токарный станок режущие инструменты CZ1440G/1
Настольный Токарный станок режущие инструменты CZ1440G/1
Настольный Токарный станок режущие инструменты CZ1440G/1
Настольный Токарный станок режущие инструменты CZ1440G/1
Настольный Токарный станок режущие инструменты CZ1440G/1
Настольный Токарный станок режущие инструменты CZ1440G/1

Настольный Токарный станок режущие инструменты CZ1440G/1

Share on (62408194053):


Price:2 875,00 $ - 2 975,00 $

Quantity:


Product Overview

Description



Product Description


Features

● Supersonic frequency hardened bed way.

● Precision roller bearing for spindle.

● High quality steel, ground and hardened gear inside headstock.
● Easy and fast operating gearbox.
● Enough strong power motor.
● ASA D4 camlock spindle nose.
● Various thread cutting function.





Specifications for CZ1440G/1
Swing Over Bed
355mm
Swing Over Carriage
220mm
Swing over gap
500mm
Distance Between Centers
1000mm
Width of bed-way
186mm
Spindle diameter
φ38/51mm
Taper of spindle
MT5
Step of speed
8
Range of speed
70~2000r.p.m
Head
D5 with D5' chuck
Metric thread
26kinds (0.4~7mm)
Inch thread
34kinds(4~56T.P.I)
Moulder thread
16 kinds(0.35~5M.P)
Diametral thread
36 kinds(6~104D.P)
Longitudinal feeds
0.091~2.533mm/r (0.002"~0.0548")
Cross feeds
0.025~0.69mm/r (0.00055"~0.015")
Diameter of lead screw
φ22(7/8")
Pitch of lead screw
3mm or 8T.P.I
Saddle travel
1000mm
Cross travel
160mm
Compound travel
70mm
Barrel travel
95mm
Barrel diameter
32mm
Taper of center
MT3
Motor power
1.5kw (2HP)
Motor for coolant system's power
0.04kw (0.055HP)
Machine(L×W×H)
1920×760×760
N.W./G.W.(main machine)
500/560kgs
